Scanivalve MPS4232 - Set the Calibrator IP Address, Port and Calibrator Number (IPCAL); Set the Calibration and Validation Average (CALAVG); Set Enable CALZ before Validation (VALZO)

64
MPS4232
Section 5: Software
RETURNS Prompt when ready to accept a new command
EXAMPLE SET DELAY 120 45 0 200
>
DEFAULT 120 0 0 300
RANGE These values are not range checked.

COMMAND IPCAL
TYPE Set/Get
DESCRIPTION Sets the IP address and port for the calibrator. This is only applicable when using a Scanivalve
SPC4000 or SPC4050 calibrator.
SYNTAX SET IPCAL <ipadd> <port> <calibrator number>
Where:
<ipadd> = Calibrator IP address.
<port> = Calibrator port.
<calibrator number> = Calibrator number.
RETURNS Prompt when ready to accept a new command
EXAMPLE SET IPCAL 10.0.0.122 23 1
>
DEFAULT 10.0.0.61 23 1
RANGE These values are not range checked.
NOTES When 0.0.0.0 0 0 is used, a simulated calibrator for debug is used.

COMMAND CALAVG
TYPE Set/Get
DESCRIPTION Sets the number of samples taken from the MPS for a calibraon and validaon.
SYNTAX SET CALAVG <calrate> <calavg>
Where:
<calrate> = Is the scan rate at which the samples are taken for the calibraon/validaon.
<calavg> = Is the number of sample taken for the calibraon/validaon. Valid values range
between 1 and 32000.
RETURNS Prompt when ready to accept a new command
EXAMPLE SET CALAVG 12 128
>
DEFAULT 0.9 16
RANGE <0 to 850> <1 to 32000>

COMMAND VALZO
TYPE Set/Get
DESCRIPTION When set (1) a CALZ is performed at the start of each temperature during a validaon.
SYNTAX SET VALZO <0 or 1>
RETURNS Prompt when ready to accept a new command
