Scanivalve MPS4232 - Calibration Variables (LIST C); List Calibration Settings (LIST C); Set Number of Points in Conversion Table (NUMPTS)

62
MPS4232
Section 5: Software

The calibraon sengs control the calibraon and validaon of the MPS4200. See Secon 6: Calibraon and Validaon Over-
view for more informaon on performing calibraons or validaons.

DESCRIPTION Returns all of the calibraon sengs
SYNTAX LIST C
RETURNS All of the calibraon sengs followed by the prompt.
EXAMPLE LIST C
SET NUMPTS 0 9 0 9
SET MIN 40.000000 -5.500000 5.000000 -5.000000
SET MAX 60.000000 5.500000 55.000000 5.000000
SET DELAY 5 5
SET IPOVEN 0.0.0.0 0
SET IPCAL 0.0.0.0 0 1
SET CALAVG 16 16
SET VALZO 0
SET FCAL 3 -5.00 5.00
SET FVAL 3 -5.00 5.00
>

COMMAND NUMPTS
TYPE Set/Get
DESCRIPTION Sets the number calibraon and validaon temperature and pressure points. This seng works
with the MIN and MAX seng to the calibraon and validaon points.
SYNTAX SET NUMPTS <tcal> <pcal> <tval> <pval>
Where:
<tcal> = Number of temperature points for a calibraon.
<pcal> = Number of pressure points for a calibraon.
<tval> = Number of temperature points for a validaon.
<pval> = Number of pressure points for a validaon.
These values are not range checked.
RETURNS Prompt when ready to accept a new command
EXAMPLE SET NUMPTS 15 25 3 15
>
DEFAULT 5 9 5 9
RANGE <0 to 15> <0 to 25> <0 to 15> <0 to 25>
