Section 5: Software

The precision me protocol sengs control the PTP 1588 sengs of the MPS4200. The PTP conguraon is accessed by the
command LIST PTP.

DESCRIPTION Returns all of the PTP sengs
SYNTAX LIST PTP
RETURNS All of the PTP seng followed by the prompt.
EXAMPLE LIST PTP
SET PTPEN 1
SET STAT 0
SET SST 0:0:0.000000
SET SSD 1971/1/1
SET UTCOFFSET -7:00:00
>

COMMAND PTPEN
TYPE Set/Get
DESCRIPTION Enables the precision me protocol engine in the MPS4200. When PTPEN is set to 2, the MPS will
serve as a PTP master.
SYNTAX SET PTPEN <status>
Where <status> is:
0 = o
1 = PTP Slave unit
2 = PTP Master unit
RETURNS Prompt when ready to accept a new command
EXAMPLE SET PTPEN 1
>
DEFAULT 0
RANGE 0 to 2
NOTES In order to set a MPS to a PTP Master (PTPEN == 2), PTP must rst be disabled (PTPEN == 0).
PTPEN 2 cannot be set when PTPEN == 1.

COMMAND STAT
TYPE Set/Get
DESCRIPTION Sets the desnaon of PTP stascal output
SYNTAX SET STAT <level code>
Where <level code> is:
0 = o
1 = serial
2 = network
