Scanivalve MPS4232 - Table of Contents

1
MPS4232
Table of Contents

 
Warnings, Cauons, and Notes iv
Warranty iv
Trademarks ® and Copyrights © v
Packaging for Shipment v
Important Noce v
Contact Informaon v
 
General Specicaons 7
Environment Specicaons 7
 
Overview 10
Module Conguraons 10
Pressure Range 10
Valve Actuaon 10
Pressure Sensors 10
Electronics 10
Pneumac Inputs 11
Power & Ethernet Connecons 11
 
Unpack & Inventory 13
Mounng 13
Environmental Consideraons 13
Warm-up 13
Communicaons 13
Serial Communicaons 13
Ethernet Communicaons 14
Seng Up an Ethernet Connecon 14
Using a Stac IPv4 address 14
PC - Web Server 15
PC - TCP/IP 15
PC - UDP 15
PC - ScanTel 15
PC - LabVIEW 15
PC - HyperTerminal 15
Scanning 16
Scan Rate 16
Scan Duraon 16
Scan Data Format 16
Scan Data Units 16
Starng a Scan 16
Scanning with an External Trigger 16
