MPS4232
Section 5: Software

The UDP sengs control the target and enable of scan data out the UDP port.

DESCRIPTION Returns all of the UDP sengs
SYNTAX LIST UDP
RETURNS All of the seng followed by the prompt.
EXAMPLE LIST UDP
SET ENUDP 0
SET IPUDP 224.0.1.2
>

COMMAND ENUDP
TYPE Set/Get
DESCRIPTION Congures UDP data output.
SYNTAX SET ENUDP <0 or 1>
Where:
0 = Disabled
1 = Enabled
RETURNS Prompt when ready to accept a new command
EXAMPLE SET ENUDP 1
>
DEFAULT 0
RANGE 0 or 1
NOTES SET FORMAT F B must be set for the MPS to send Binary data via UDP.

COMMAND IPUDP
TYPE Set/Get
DESCRIPTION Sets the UDP data output target address and port.
SYNTAX SET IPUDP <udpadd> <port>
Where:
<udpadd> = Is the target IP address for the UDP scan data.
<port> = Is the target port.
RETURNS Prompt when ready to accept a new command
EXAMPLE SET IPUDP 224.0.1.2 23
>
DEFAULT 0.0.0.0 0
RANGE <Any valid IP address> <0-65535>
