Scanivalve MPS4232 - Set Scan Units (UNITS)

49
MPS4232
Section 5: Software
DESCRIPTION Sets the number of frames to output during a scan. Once this number of frames is met during a
scan, the MPS will stop scanning and return to READY mode.
A Frame contains a sampled pressure value per channel output (32 channels total) plus me
stamp, frame number, temperatures, and other addional informaon dened by the data output
congured in the MPS.
The FPS variable can be used to congure a scan for a certain me duraon using the following
equaon:
FPS = RATE x TIME
where RATE is expressed in Hertz and TIME is expressed in seconds
SYNTAX SET FPS <number of frames>
Where <number of frames> is the number of frames in a scan. When set to 0 the scan
connues unl the STOP command is issued.
RETURNS Prompt when ready to accept a new command
EXAMPLE SET FPS 100
>
DEFAULT 0
RANGE 0 to 4294967295

COMMAND UNITS
TYPE Set/Get
DESCRIPTION Set the scan units (pressure engineering units)
SYNTAX SET UNITS <units> [<user cv>]
Where <units> is one of the following:
PSI ATM BAR CMHG
CMH2O DECIBAR FTH2O GCM2
INHG INH2O KNM2 KGM2
KGCM2 KPA KIPIN2 MPA
MBAR MH2O MMHG NM2
NCM2 OZIN2 OZFT2 PA
PSF TORR USER RAW
When <units> is set to USER, the user must enter a value for <user cv>.
RETURNS Prompt when ready to accept a new command
EXAMPLE // To congure the EU output to PSI
UNITS PSI
>
EXAMPLE // To congure a user conversion value
UNITS USER 1.50
>
