MPS4232
Section 1: Introduction Section 1: Specifications
MPS4232


Size (WxHxD) (includes tubes)
0.5” x 1.62” x 4.13”
[12.7mm x 41.15mm x 104.78mm]
Weight 0.19lbs [86.2g]
Inputs (Px) 0.042” [1.067mm] OD
(standard)
0.031” [.787mm] OD
(oponal)
Inputs (REF) 0.063” [1.600mm] OD
Standard Full Scale Ranges* ±4 inH2O, ±8 inH2O,
±1psid, ±5psid, ±15psid,
50psid
[995.4Pa, 1990.7Pa,
6.89kPa, 34.5kPa,
103.4kPa, 344.7kPa]
* Modules calibrated at +15PSI F.S. or higher are only calibrated to -15PSI.
Accuracy**
4 inH
2
O ±0.20% FS
8 inH
2
O ±0.15% FS
1psid ±0.06% FS
5psid ±0.06% FS
15psid ±0.06% FS
50psid ±0.06% FS
** Including linearity, hysteresis, and repeatability.
Overpressure (No damage)
4 inH
2
O 2psi
8 inH
2
O 2psi
1psid 10psi
5psid 40psi
15psid 75psi
50psid 200psi
Maximum
Reference Pressure 50psig (344.7kPa) or
overpressure range,
whichever is less
Data Output Rate*** - Hz (samples/channel/second)
Binary 1000Hz
ASCII 100Hz
*** maximum data rate depends on network
A/D Resoluon 24bit
Ethernet Connecon 100baseT
MDIX auto-crossing
Communicaons
Ethernet IEEE802.3
TCP/IP HTTP, Telnet, FTP
UDP
Precision Time Protocol IEEE1588-2008v2
Power Requirements 5-36Vdc, 3.5W
External Trigger 5-15Vdc, 6.5mA
Mang Connectors
Ethernet TE Connecvity PLG 8P8C Mini2
Power TE Connecvity PLG 8P8C Mini1

Temperature
Operaon 0 to 70°C
Storage 0 to 80°C
Compensated 0 to 70°C
Humidity
Operaon 5 to 95% RH, Non-Condensing
Storage 5 to 95% RH, Non-Condensing
Shock & Vibraon MIL-STD-810G, Category 24
Media Gasses compable with
Silicon, Silicone,
Aluminum and Buna-N
Maximum
Environmental Pressure 100psia (690kPa absolute)
Minimum
Environmental Pressure 0.50psia (3.45kPa absolute)
Standards: CE & RoHS v3
