2
MPS4232
Table of Contents
Seng up an External Frame Trigger 17
Seng up an External Scan Trigger 17
Scan-on-Startup Opon 17
Scan Data Output Methods 17
ASCII TCP Scan Data Transfer 17
Binary TCP Scan Data Transfer 18
FTP Scan Data Transfer 18
UDP Scan Data Transfer 18
Binary Data Buering 18
Zero Oset Calibraons (CALZ) 19
IEEE1588v2 Precision Time Protocol 19
PTP Triggered Scan 19
Mulple Unit Operaons 20
Mulple Unit Scan Command 20
Mulple Unit Stop Command 21
Mulple Unit Find Command 21
Web Server 22
Web Server: Main Display 23
Web Server: Scan 24
Web Server: File Browser 26
 
Pneumac Connecons 28
Basics of Connecng Input Tubes 28
Pressure Measurement (Px) Ports 28
Reference (REF) Port 28
Removable Pressure Input Headers 28
Electrical Connectors 29
Power/Serial/Trigger Connecon 29
Ethernet Connector 29
 
Overview 32
MPS Commands 32
MPS4200 Buer Descripon 33
MPS Network Conguraons 33
Isolated Network 33
Integrated with System Network 33
Sub-Network with Gateway 33
MPS Data Output Denions 33
Host to MPS Command Packet 33
MPS to Host ASCII Packet 33
Scan Data Formats 34
ASCII Scan Data Examples 34
Unformaed ASCII 34
Formaed ASCII 35
Comma Separated Variable ASCII 35
Binary Scan Data Formats 35
Table 5.1 - Standard 32 Channel Binary Data Packet 35
Table 5.2 - Padded 64 Channel Binary Data Packet 36
