Crc Errors whole packet:
The number of CRC errors calculated over the whole T2MI packet
since the monitoring of the stream started.
L1 information:
T2 version:
The version of the T2 spec used. Up to version 1.3.1 is supported including
T2 lite.
Type: The type of data carried in the Transport stream.
T2 lite profile used:
Set to true if the T2 lite profile is used for sending power efficient broadcasts
to portable clients.
BW ext: The carrier mode (normal or extended).
S1: T2-SISO, T2-MISO or Non-T2.
S2: FFT mode and guard interval.
PAPR: The PAPR reduction mode (if any).
Pilot pattern: Pilot pattern PP1 to PP8.
TX ID availability: Should always be set to ‘No transmitter identification signals are used’.
Cell id: The cell ID for the transmitter.
Network id: The network id for this DVB-T2 network.
T2 system id: The T2 system id.
L1 post scrambling: Says whether post scrambling is used or not.
L1 modulation: The L1 modulation type used. BPSK, QPSK, 16-QAM or 64-QAM.
L1 FEC type: The L1 fec type in use. Only ‘LDPC 16K’ is currently supported in DVB-T2.
L1 repetition: Shows if dynamic signaling is provided.
L1 post size: The L1 post size.
L1 post info size: The L1 post info size.
L1 post extension: Shows if extension field is provided.
L1 change counter: The value of the L1 change counter.
Guard interval: The guard interval used for the transmission. 1/32, 1/16, 1/8 or 1/4.
Num T2 frames: The number of T2 frames signaled.
Num data symbols: The number of data symbols signaled.
Sub slices per frame: How many sub slices are used per T2 frame.
Num aux: The number of auxiliary channels transmitted.
Aux config rfu: The aux config rfu number.
Number of RF: The number of RF frequencies used to transmit the signal.
Frequencies:
The list of frequencies used to transmit the signal. Normally only one
frequency will be used.
Current RF index: The index of the frequency currently being used for the transmission.
VB2xx GigE User’s Manual version 5.4 141
