Static padding:
Says whether the padding is static or can change between each BB frame.
PLP start: The start value for the PLP in the stream.
PLP num blocks: The number of blocks used for this PLP.
6.9.9 ETR 290 — SCTE 35 (requires SCTE35-OPT)
SCTE 35 is a specification which allows equipment to splice in local content at specific times, SCTE 35
is basically just the signaling mechanism the equipment uses to know when to switch from the master
transmission to insert local content. It can be used to allow insertion of local advertising at certain points
in time or to allow the local operator to insert their own programs such as local news transmission.
SCTE 35 requires a license for the probe and also an ETR 290 engine to connect it to.
The SCTE 35 option enables monitoring of SCTE 35 events of all streams captured by the ETR engines.
It is recommended to one ETR engine dedicated to each SCTE 35 streams to get continuous monitoring.
The stream list parameters
Stream name: Name specified by the user when adding a multicast or tuning.
Interface: The input source of the transport stream.
Services incl. SCTE 35:
The number of services in the transport stream which has SCTE 35
information.
Events: The number of SCTE 35 events occurred in a transport stream.
144 VB2xx GigE User’s Manual version 5.4
