Time min: The minimum time an impulse should occur after the main impulse
Time max: The maximum time an impulse should occur after the main impulse
Power min:
The minimum power of an impulse compared to the main impulse (in dB)
Power max:
The maximum power of an impulse compared to the main impulse (in dB)
6.12.4 COFDM — Impulse response (Requires Advanced RF Option)
The impulse response graph displays impulses as a function of time and power with reference to the
main impulse. If impulse threshold values have been assigned to DVB-T/T2 stream (frequency) these will
190 VB2xx GigE User’s Manual version 5.4
