Menu: /ewe/probe/core/setup/ethernet/

==============================================================================

<0> Back <9> Exit

<1> ethStatusDoc

------------------------------------------------------------------------------

<A> data_medium - Copper Input for the video traffic

<B> data_dhcp - false RJ45 data port (eth0) DHCP

<C> data_ipa - 10.0.30.101 RJ45 data port (eth0) IP address

<D> data_mask - 255.255.255.0 RJ45 data port (eth0) netmask

<E> data_gateway - 10.0.30.1 RJ45 data port (eth0) IPv4 GW

<F> data_management - true RJ45 data port (eth0) web-server

<G> dhcp - false Management port (eth1) DHCP

<H> ipaddress - 10.0.20.101 Management port (eth1) IP address

<I> netmask - 255.255.255.0 Management port (eth1) netmask

<J> mm_gateway - 10.0.20.1 Management port (eth1) IPv4 GW

<K> management - true Management port (eth1) web-server

<L> gateway_interface - eth0 Force default interface

<M> dns_server - 208.67.222.222 DNS Server

<N> reboot - false

------------------------------------------------------------------------------

Figure 4.15: Text-based menu displayed when connecting over USB

To conﬁgure the management interface, edit values for ipaddress, netmask and mm_gateway or enable

dhcp instead.

Make sure Management is enabled (set to true) – otherwise management via web will not be possible.

To conﬁgure the data/video interface, enter values for data_ipa, data_mask, data_gateway or alternatively

enable data_dhcp. Set data_management to true to enable web access via the data interface.

When all the listed parameters have been conﬁgured, the probe must be rebooted to let the parameters

take effect. This is achieved by selecting the reboot option and conﬁrming by selecting ‘t’ for TRUE.

4.11.3 Verifying Correct Initial Setup of the Probe

Once the probe management network interface have been conﬁgured, all further conﬁguration takes

place using a web browser over HTTP.

Launch a web browser application on the management PC. The following web browsers are supported:

• Google Chrome

• Mozilla Firefox

36 VB2xx GigE User’s Manual version 5.4
