Enable tuning:
If this box is checked the transport stream associated with the current fre-
quency will be monitored
It is also possible to add new frequencies manually by copying existing tuning list entries using the
Duplicate highlighted button.
Multi-edit functionality makes it possible to edit several threshold templates simultaneously. Highlight the
tuning list entries that should be edited and click the Edit selected button.
Note that all tunings will automatically be ETR 290 analyzed, and hence be part of the round-robin loop
unless the ‘Enable tuning’ box is unchecked.
6.13.3 ISDBT — ISDB-T threshold
The probe will raise an alarm if one of the threshold settings associated with a tuning is violated. Note
that this alarm may be disabled in the ETR 290 — ETR thr. — Edit view (Input interface checks).
In the threshold template list the ‘Refs’ column shows how many streams are associated with each
template.
To add a new threshold template to the list, click the
Add new threshold
or
Duplicate selected
button.
A pop-up window will appear allowing the user to enter parameters.
One or more threshold templates may be deleted or edited by highlighting them and clicking the
Delete
selected or Edit selected button.
The predefined threshold templates Default and Analog carrier cannot be edited or deleted.
196 VB2xx GigE User’s Manual version 5.4
