Modulation: The QAM modulation mode: 16, 32, 64, 128 or 256 QAM.
Mode: The QAM transmission mode: DVB-C (Annex A), QAM-B (Annex B) or 8VSB
TS sync: Transport stream sync: yes or no
Min level: The minimum RF signal level
Max level: The maximum RF signal level
Min SNR: The minimum signal to noise ratio
Min MER: The minimum modulation error ratio
Max pre FB: The maximum bit error rate before forward error correction
Max post FB: The maximum bit error rate after forward error correction
Max CFO: The maximum center frequency offset
Max SRO: The maximum symbol rate offset)
6.15 SAT (VB272 Option for VB220)
The SAT tab will only be present in the graphical user interface provided that the probe chassis is
equipped with an optional DVB-S/S2 demodulator module.
The VB272 DVB-S/S2 option module offers two independent RF input modules. For the VB272 one input
is active by default and the second input can be activated through the SECOND-RF-INPUT-OPTION
license key.
If demodulator cards are present in the chassis each RF input will be labeled SAT1, SAT2 up to SAT4 in
the case of two VB272 modules being installed. SAT1 being the leftmost, as seen from the front of the
unit.
Thumbnails of SAT services are accessed from the
ETR 290 — Services
and
Main — Thumb overview
views.
206 VB2xx GigE User’s Manual version 5.4
