Maximum symbol rate offset: Threshold level for maximum symbol rate offset (sym/s)
Symbol rate zero adjust:
Allows to define calibration adjustment for symbol rate offset (sym/s)
6.15.5 SAT — RF overview
The RF parameters and measurements list gives a status overview of all monitored SAT frequencies
from the selected RF input. The parameters and measurements in this list refer to the last completed
monitoring period or, for a stream currently monitored, the current monitoring period.
6.16 SAT Redundancy Switch (VB272 and VB273 Option for
VB220)
6.16.1 Tuning setup
The redundancy switch requires two additional blades, a VB272 and a VB273 in the same chassis. The
Redundancy tab is located next to the corresponding SAT tabs.
Both of the RF outputs on the VB273 blade must be connected into the corresponding inputs on the
VB272 blade
216 VB2xx GigE User’s Manual version 5.4
