DVB-T2 L1 PLP Information:
Id: The PLP (Physical Layer Pipe) Id.
Type: The type of the PLP. ‘Common type’, ‘Data 1’, ‘Data 2’.
Group id: The group of PLPs that this PLP belongs to.
Constellation:
The constellation of the current PLP. ‘QPSK’, ‘16-QAM’, ‘64-QAM’, ‘256-
QAM’.
Code rate:
The code rate of this PLP. ‘1/2’, ‘2/3’, ‘3/5’, ‘3/4’, ‘4/5’ - DVB-T2 Base only,
‘5/6’ - DVB-T2 Base only, ‘1/3’ - DVB-T2 Lite only, ‘2/5’ - DVB-T2 Lite only.
Rotated: Indicates if constellation is rotated. ‘True’ or ‘False’.
FEC: The FEC (Forward Error Correction) type used on this PLP. ‘LDPC (Low-
density parity-check) 16K (Short FECFrame)’, ‘LDPC (Low-density parity-
check) 64K (Long FECFrame)’. - DVB-T2 Base Only.
Num blocks: Maximum number of PLP blocks.
Frame interval: The T2 frame interval within the super frame of this PLP.
Time interleaver length: Time interleaver length.
Time interleaver type: Indicates type of Time Interleaver.
In band A signaling:
In-band A flag. Indicates whether PLP carries in-band signaling. ‘True’ or
‘False’.
In band B signaling:
In-band B flag, Indicates whether PLP carries in-band signaling. ‘True’ or
‘False’.
In band B TS rate: In-band B signaling TS rate.
Payload:
The payload carried by the PLP. ‘GFPS (Generic Fixed-length Packetized
Stream)’, ‘GCS (Generic Continuous Stream)’, ‘GSE (Generic Encapsu-
lated Stream)’, ‘TS (Transport Stream)’
Null packet detection: Null packet detection indicator. ‘True’ or ‘False’.
ISSY: Input Stream Synchronization Indicator. ‘True’ or ‘False’.
Mode:
PLP (Physical Layer Pipe) Mode. ‘HEM (High Efficiency Mode)’, ‘Normal’
DVB-T2 L1 Post Information
Sub Slices per frame: The number of sub-slices per T2 Frame.
PLP count: The number of PLPs (Physical Layer Pipes) in the current super frame.
Aux count: Number of auxiliary streams.
Aux config: Auxiliary stream config.
RF index: The RF index.
Frequency (Hz): The frequency in Hz for the given RF index.
FEF type: Indicates the type of FEF (Future Extension Frames) part.
FEF length:
The length of the FEF (Future Extension Frames) as part of the elementary
period.
184 VB2xx GigE User’s Manual version 5.4
