Technical Data
Technical data of braking resistors, filters and chokes
Operating Instructions – MOVIDRIVE
®
modular
239
Technical data and assignment to an inverter
Technical Data
Braking resistor Unit BW047-002 BW047-010-T BW027-016-T BW027-024-T
Part number 08281661 17983207 17983215 17983231
Nominal power P
N
kW 0.2 1 1.6 2.4
Resistance value R
BW
Ω 47 ± 10% 47 ± 10% 27 ± 10%
Tripping current I
F
A 1.6 4.6 7.7 9.4
Design Flat-type resistor Wire resistor
Power connections - 0.75 – 10 mm
2
Tightening torque Nm - 1.5 – 1.8
PE connection - M6 stud
Tightening torque PE Nm - 1.8
Degree of protection IP65 IP20
Ambient temperature ϑ
amb
-20°C to +40°C
Mass kg 0.6 4 5.8 8
Assignment to an inverter
Braking resistor Unit BW047-002 BW047-010-T BW027-016-T BW027-024-T
Assignment to MDP90A. 0100 – 1100
Technical Data
Braking resistor Unit BW012-016 BW012-024 BW012-050-T
Part number 18213243 17983894 18201407
Nominal power P
N
kW 1.6 2.4 5
Resistance value R
BW
Ω 12 ± 10%
Tripping current I
F
A 11.5 14.1 20.4
Design Wire resistor Grid resistor
Power connections 0.75 – 10 mm
2
M8 stud
Tightening torque Nm 1.5 – 1.8 6
PE connection M6 stud M6 stud
Tightening torque PE Nm 1.8 Nm 3
Degree of protection IP20
Ambient temperature ϑ
amb
-20°C to +40°C
Mass kg 5.8 8 12
Assignment to an inverter
Braking resistor Unit BW012-016 BW012-024 BW012-050-T
Assignment to MDP90A. 0250 – 1100
Technical Data
Braking resistor Unit BW106-T BW206-T BW005-070 BW004-050-01 BW002-070 BW003-420-T
Part number 18200834 18204120 17983282 18200133 17983304 13302345
Nominal power P
N
kW 13.5 18 7 5 7 42
Resistance value R
BW
Ω 6 ± 10% 4.7 ± 10% 3.6 ± 10% 2.3 ± 10% 2.5 ± 10%
Tripping current I
F
A 47.4 54.7 38.6 37.3 55.2 135.1
Design Grid resistor
Power connections M8 stud M8 stud M12 stud
Tightening torque Nm 6 6 15.5
PE connection M6 stud M6 stud M10 stud
Tightening torque PE Nm 3 3 10
Degree of protection IP20
Ambient temperature ϑ
amb
-20°C to +40°C
Mass kg 30 40 13 12 33 93
