Technical Data

Technical data of braking resistors, filters and chokes

Operating Instructions – MOVIDRIVE

modular

240

Assignment to an inverter

Braking resistor Unit BW106-T BW206-T BW005-070 BW004-050-01 BW003-420-T BW002-070

Assignment to MDP90A. 0500 – 1100 0750 – 1100 1100

Technical data BW..-T signal contact

Specifications for BW..-T signal contact Design

Connection contacts 0.75 – 2.5 mm

Tightening torque 0.6 Nm

Switching capacity DC 2 A / DC 24 V (DC11)

AC 2 A / AC 230 V (AC11)

Switch contact (NC contact) According to EN61800-5-1

24748536/EN – 11/2017
