1-146
BEFORE USING THE MACHINEâ–ºMAINTENANCE
CLEANING THE MAIN CHARGER OF THE
PHOTOCONDUCTIVE DRUM
If black lines or coloured lines appear even after you have cleaned the document glass and automatic document feeder,
use the charger cleaner to clean the main charger that charges the photoconductive drum.
MX-2630N/MX-3050N/MX-3070N/MX-3550N/MX-3570N/MX-4050N/MX-4070N only
The charger is automatically cleaned on the MX-5050N/MX-5070N/MX-6050N/MX-6070N. The charger cleaner cannot be
used.
â–º MC Cleaning Mode (MX-5050N/MX-5070N/MX-6050N/MX-6070N only) (page 7-173)
1
Open the front cover.
2
Remove the waste toner box.
Press the release buttons on the sides of the waste toner
box inward and pull out slowly.
3
Remove the charger cleaner.
The charger cleaner is attached to the front cover.
(1) Pull the right-hand side of the charger
cleaner to detach it from the hook.
(2) Put it over the hook to place it on the back
side.
(3) Turn the charger cleaner around the boss
to detach it from the left hand hook.
To Next Page
