4-25
FACSIMILEâ–ºBASIC TRANSMISSION METHODS
ORIGINAL ORIENTATION
When an A4 (8-1/2" x 11") original is placed in vertical orientation ( ), the image is automatically rotated 90 degrees
and transmitted in horizontal orientation ( ) (Rotation Sending).
If the original is placed in horizontal orientation ( ), it is transmitted in that orientation ( ) without being rotated.
Rotation sending is not available for originals with A4R, B5, or A5 (8-1/2" x 11" or 5-1/2" x 8-1/2") size.
To cancel the rotation sending setting:
In "Settings (administrator)", select [System Settings] → [Image Send Settings] → [Fax Settings] → [Send Settings] →
[Rotation Sending Setting].
If this setting is disabled, the original will be transmitted in the orientation in which it is placed.
Because of this, some receiving machines may reduce the received data.
A4 (8-1/2" x 11") Rotated to
A4R (8-1/2" x 11")
orientation
A4R (8-1/2" x 11") image is
transmitted.
