1-160
BEFORE USING THE MACHINEâ–ºMAINTENANCE
REPLACING THE STAMP CARTRIDGE
If a stamp unit (AR-SU1) is installed on the automatic document feeder and the stamp has become light, replace the
stamp cartridge (AR-SV1).
Supplies
Stamp cartridge (2 in package) AR-SV1
When using the MX-3070N/MX-3570N/MX-4070N/MX-5070N/MX-6070N
1
Open the automatic document feeder.
2
Remove the document backplate sheet
from the automatic document feeder.
Remove the sheet slowly. Place the removed sheet with the
side that was attached face up on the document glass.
3
Grasp the tab on the stamp unit and
pull the unit out.
4
Remove the stamp cartridge (A).
To Next Page
