Sharp MX-2314N Service Manual

MX-3114N SPECIFICATIONS 2 – 3
(7) Paper feed section
a. Basic specifications
b. Extra paper capacity
c. Size of paper which can be fed
Type Standard 1-stage paper feed tray + multi manual paper feed
tray
Full option 4-stage paper feed tray + multi manual paper feed
tray
Dehumidifying
heater
Service parts (Supported by kit)
Tray Tray 1 Manual paper feed tray
Paper capacity
Plain paper
(80g/m
2
)
500 sheets 100 sheets
Paper size Refer to the separate table of feedable paper type.
Paper size
detection
No (Guide adjustment
and size input)
Yes
Paper type settings Yes
Changing of paper
size
Switched by users
Universal handle Yes
(With the handle lock
mechanism)
-
Default Paper Size
Setting
A4 (8.5" x 11") -
Paper remaining
quantity detection
Paper empty and 3
steps (100%, 67%, 33%,
and paper empty)
Only detection of paper
empty
Paper size display
window
Yes -
Paper type Paper feed tray Manual feed tray
Postcard NA 20 sheets
Envelope NA 20 sheets
OHP NA 20 sheets
Heavy paper 200 sheets 40 sheets
Tab paper NA 20 sheets
Glossy paper NA 1 sheet
Others NA 1 sheet
Paper feed section
Main unit
tray
Optional Drawer
Manual
paper
feed tray
Tray 1 Tray 2 Tray 3 Tray 4
Tandem
(Left)
Tandem
(Right)
Paper
size
12" x 18" (A3W) - - - - - - Yes
11" x 17" Yes Yes Yes Yes - - Yes
8.5" x 14" (216 x 356) Yes Yes Yes Yes - - Yes
8.5" x 13.5" (216 x 343) Yes Yes Yes Yes - - Yes
8.5" x 13.4" (216 x 340) Yes Yes Yes Yes - - Yes
8.5" x 13" (216 x 330) Yes Yes Yes Yes - - Yes
8.5" x 11" Yes Yes Yes Yes Yes Yes Yes
8.5" x 11"R Yes Yes Yes Yes - - Yes
7.25" x 10.5"R Yes Yes Yes Yes - - Yes
5.5" x 8.5"R Yes Yes Yes Yes - - Yes
A3 Yes Yes Yes Yes - - Yes
B4 Yes Yes Yes Yes - - Yes
A4 Yes Yes Yes Yes Yes Yes Yes
A4R Yes Yes Yes Yes - - Yes
B5 Yes Yes Yes Yes - - Yes
B5R Yes Yes Yes Yes - - Yes
A5R Yes Yes Yes Yes - - Yes
8K Yes Yes Yes Yes - - Yes
16K Yes Yes Yes Yes - - Yes
16KR Yes Yes Yes Yes - - Yes
JPC *
1
------Yes
Envelope - - - - - - Yes
Custom Yes Yes - - - - Yes
Long paper
Width: 125-297mm
Length: 433-1200mm
------Yes
Paper
type
Thin paper 13-16lb bond (55-59g/m
2
)NoNoNoNoNoNoYes
Plain paper 16-28lb bond (60-105g/m
2
) Yes Yes Yes Yes Yes Yes Yes
Recycled paper Yes Yes Yes Yes Yes Yes Yes
Color paper Yes Yes Yes Yes Yes Yes Yes
Letter head Yes Yes Yes Yes Yes Yes Yes
Pre printed Yes Yes Yes Yes Yes Yes Yes
Pre Punched Yes Yes Yes Yes Yes Yes Yes

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
