Sharp MX-2314N Service Manual

MX3114N TROUBLESHOOTING 7 – 6
F. Error code list
Trouble
code
Trouble content
Trouble
detection
Mechanism Option Electricity FAX Supply
Main
code
Sub
code
A0 01 PCU PWB ROM error MFP 
02 SCU PWB ROM error MFP 
10 Color profile error MFP 
11 Firmware version inconsistency (MFP - PCU) MFP 
15 Incompatible DSK BOOT and program firmware MFP 
16 Data error of the energy-saving NIC controller firmware in the SD card MFP 
20 Conflict firmware and EEPROM data version (MFP) MFP 
21 Conflict firmware and EEPROM data version (PCU) PCU 
22 Conflict firmware and EEPROM data version (SCU) SCU 
C1 10 Main charger trouble (Monochrome) PCU 
14 Main charger trouble (Color) PCU 
C4 00 PTC trouble (TC high voltage trouble) PCU 
E7 01 MFP image data error MFP 
03 HDD trouble MFP 
04 HDD-ASIC error MFP 
07 SD card error MFP 
10 Shading error (Black correction) SCU 
11 Shading error (White correction) SCU 
14 CCD-ASIC error SCU 
20 LSU laser detection error (K) PCU 
21 LSU laser detection error (C) PCU 
22 LSU laser detection error (M) PCU 
23 LSU laser detection error (Y) PCU 
28 LSU - PCU connection error PCU 
29 LSU ASIC frequency error PCU 
49 Water Mark data error MFP 
50 Combination error between PWB and firmware (PCU PWB detection) PCU 
55 PCU PWB information sum error PCU 
60 Combination error between PWB and firmware (MFPC PWB detection) MFP 
61 Combination error between the MFPC PWB and the PCU PWB
(MFPC PWB detection)
MFP 
65 MFP EEPROM sum check error(26/31cpm machine) MFP 
80 MFP - SCU PWB communication error MFP 
89 Communication error between MFPC PWB CPU and energy-saving NIC
controller
MFP 
90 MFP - PCU PWB communication error MFP 
91 FAX reception image data error MFP 
92 Copy image data error MFP 
93 Copy, image send, FAX, filing, print image data process error MFP 
94 Image file data process error (when importing file data) MFP 
95 SoC DRAM memory check error MFP 
96 MFPC PWB memory check error MFP 
EE EC Automatic toner density adjustment error PCU 
EL Automatic toner density adjustment error (Over toner) PCU 
EU Automatic toner density adjustment error (Under toner) PCU 
F1 00 Finisher - PCU PWB communication error PCU 
03
Finisher paper exit roller lifting operation trouble PCU 
08 Stapler shift trouble PCU 
10 Staple operation trouble PCU 
15 Finisher paper exit tray lift operation trouble PCU 
19 Finisher alignment operation trouble F PCU 
20 Finisher alignment operation trouble R PCU 
21 Finisher fan trouble PCU 
33 Punch unit shift operation trouble PCU 
34 Punch operation trouble PCU 
37 Finisher data backup RAM error PCU 
50 Main unit - Finisher combination error PCU 

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
