Sharp MX-2314N - Stand;3 X500 Sheet Paper Drawer

MX-3114N MAINTENANCE 9 – 42
(3) Stand/3x500 sheet paper drawer
Unit work
sequence
Unit name
Parts work
sequence
Part name
When
calling
At the
machine cycle
Remark
1 Tray 2 paper feed unit 1 Paper pickup roller ✕  Replace at 100K of each tray paper feed
counter or 1 year of use.
2 Paper feed roller ✕ 
3 Separation roller ✕ 
4 Transport roller 1 ✕ 
5 Torque limiter ✕✕Replace at 100K of each tray paper feed
counter.
6Sensors ✕✕
– Paper guides Clean with alcohol.
2 Tray 3 paper feed unit 7 Paper pickup roller ✕  Replace at 100K of each tray paper feed
counter or 1 year of use.
8 Paper feed roller ✕ 
9 Separation roller ✕ 
10 Vertical transport roller 1 ✕ 
11 Transport roller 3 ✕ 
12 Torque limiter ✕✕Replace at 100K of each tray paper feed
counter.
13 Sensors ✕✕
– Paper guides Clean with alcohol.
3 Tray 4 paper feed unit 14 Paper pickup roller ✕  Replace at 100K of each tray paper feed
counter or 1 year of use.
15 Paper feed roller ✕ 
16 Separation roller ✕ 
17 Vertical transport roller 2 ✕ 
18 Transport roller 5 ✕ 
19 Torque limiter ✕✕Replace at 100K of each tray paper feed
counter.
20 Sensors ✕✕
– Paper guides Clean with alcohol.
4 1CS drive unit 21 Gears (grease) ✕✕Apply to the specified position when checking.
HANARL FL-955R
22 Shafts (grease) ✕✕Apply to the specified position when checking.
FLOIL G-313S
5 2CS drive unit 23 Gears (grease) ✕✕Apply to the specified position when checking.
HANARL FL-955R
24 Shafts (grease) ✕✕Apply to the specified position when checking.
FLOIL G-313S
6 3CS drive unit 25 Shafts (grease) ✕✕Apply to the specified position when checking.
FLOIL G-313S
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ
