MX-3114N SPECIFICATIONS 2 – 2
*1: The printable area for A3W/12" x 18" must be as large as the
A3/11" x 17" page full bleed (299 x 450mm).
(4) Engine resolution
*1: Resolustion: 600dpi (default)
*2: The Dither and Error Diffusion methods using 8 bit input will be
performed.
(5) Scanner section
a. Resolution/Gradation
b. Document table
(6) Document feeder
Void area
Image loss
Lead edge: 4mm or less
Rear edge: 2 mm or more, and 5 mm or less
Total of the lead edge and the rear edge: 8mm or less
FR total: 4mm±2mm or less
Resolution*
1
Copy Writing
600 x 600dpi
9,600 (equivalent) x 600dpi
Print Writing
600 x 600dpi
9,600 (equivalent) x 600dpi
Gradation *
2
(256 levels)
Copy Writing
600 x 600dpi x 4bit
9,600 (equivalent) x 600dpi
Print Writing
PCL:
600 x 600dpi x 1bit
600 x 600dpi x 4bit
9,600 (equivalent) x 600dpi
PS:
600 x 600dpi x 1bit
600 x 600dpi x 4bit
9,600 (equivalent) x 600dpi
Scanning
Resolution (dpi)
Monochrome Color
Platen 600 x 600dpi
600 x 400dpi
600 x 300dpi (default)
600 x 600dpi
RSPF 600 x 600dpi
600 x 400dpi (default)
600 x 600dpi
Exposure lamp White LED
Reading gradation 10bit
Output gradation BW: 1bit
Grayscale: 8bit
Full Color: each color RGB 8bit
Type Document table fixed system (Flat bed)
Scanning area 297 x 432mm
Original standard
position
Left rear reference
Detection Yes
Detection size Automatic detection (One type of detection unit to
be switched for software destination)
Dehumidifying
heater (Scanner
section)
Supplied as a service parts
Type RSPF (Reversing single pass feeder)
Scan speed Monochrome
(A4/8.5" x 11")
Color (A4/8.5" x 11")
Copy Single:
50-sheet/min.
(600 x 400dpi, 4bit)
36-sheet/min.
(600 x 600dpi, 4bit)
Double:
20-page/min.
(600 x 400dpi, 4bit)
17-page/min.
(600 x 600dpi, 4bit)
Single:
36-sheet/min.
(600 x 600dpi, 4bit)
Double:
17-page/min.
(600 x 600dpi, 4bit)
FAX Single: 50-sheet/min.
(200 x 200dpi, 1bit)
Double: 20-page/min.
(200 x 200dpi, 1bit)
NA
Internet FAX Single: 50-sheet/min.
(200 x 200dpi, 1bit)
Double: 20-page/min.
(200 x 200dpi, 1bit)
NA
Scanner Single: 50-sheet/min.
(200 x 200dpi, 1bit)
Double: 20-page/min.
(200 x 200dpi, 1bit)
Single: 50-sheet/min.
(200 x 200dpi, 8bit)
Double: 20-page/min. (200
x 200dpi, 8bit)
Original setup
direction
Upward standard (1 to N feeding standard)
Original standard
position
Center standard (Rear one-side standard for
random feeding)
Original transport
method
Sheet-through method
Original size Standard size
Inch-1: 11" x 17", 8.5" x 14", 8.5" x 11", 8.5" x 11"R,
5.5" x 8.5", A3, A4
Inch-2: 11" x 17", 8.5" x 13", 8.5" x 11", 8.5" x 11"R,
5.5" x 8.5", A3, A4
Inch-3: 11" x 17", 8.5" x 13.4", 8.5" x 11",
8.5" x 11"R, 5.5" x 8.5", A3, A4
AB-1: 11" x 17", 8.5" x 14", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-2: 11" x 17", 8.5" x 13", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-3: 11" x 17", 8.5" x 13", 8.5" x 11", A3, B4, A4,
A4R, A5, 8K, 16K, 16KR
AB-4: 11" x 17", 8.5" x 13.4", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-5: 11" x 17", 8.5" x 13.5", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
Long
paper
1000 mm (Monochrome binary only)
Internet Fax 600 x 600 dpi: Max. 800 mm.
When scan 400 dpi or more, long paper
is not available.
Mix paper feed
(Same series,
same width paper)
Enabled
Random feeding
(feeding of different
types / different
widths)
Enabled
Only the following combinations of 2 size types are
allowed:
A3 and B4; B4 and A4R; A4 and B5; B5 and A5;
and 11-inch and 8.5-inch. AMS available. 2-sided
scanning is disabled during random feeding.
Original copy
weight
Single:
Thin paper: 9 - 13 lb bond (35 - 49 g/m
2
)
Plain paper: 13 - 32 lb bond (50 - 128 g/m
2
)
* Thin paper mode (39 pages/minute (A4, 8.5" x
11", 600 x 400dpi) / 26 pages/minute (A4, 8.5" x
11", 600 x 600dpi) is set up for the thin paper.
Duplex: 13 - 28 lb bond (50 - 105 g/m
2
)
Max. loading
capacity of
documents
Max. 100 sheets (21lbs Bond, 80g/m
2
), or Max.
height: 1/2 inch, 13mm or less
Un-acceptable
originals for
feeding.
OHP, second original paper, tracing paper, carbon
paper, thermal paper, paper with wrinkles, folds, or
breakage, pasted paper, cutout document,
document printed with ink ribbon, documents with
perforation other than 2- or 3-holes (Perforated
document by punch unit is allowed.)
Detection Yes
Paper detection
size
Auto detection
Paper feeding
direction
Right hand feeding
Finish stamp Option

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
