Sharp MX-2314N Service Manual

MX-3114N CONSUMABLE PARTS 3 – 1
MX-3114N
Service Manual
[3] CONSUMABLE PARTS
1. Supply system table
(1) Europe, Australia, New Zealand, Korea
(2) Asia, Hong Kong
Item Content Life Model name
Quantity in
collective
package
Remarks
Toner cartridge
(Black)
Toner cartridge (Black toner) x 1 18K MX-23GT-BA 10 * Life: A4/Letter size at area
coverage 5%
(Reference: 15K for A4/Letter
6%)
Toner cartridge
(Cyan)
Toner cartridge (Cyan toner) x 1 10K MX-23GT-CA 10 * Life: A4/Letter size at area
coverage 5%
Toner cartridge
(Magenta)
Toner cartridge (Magenta toner) x 1 10K MX-23GT-MA 10
Toner cartridge
(Yellow)
Toner cartridge (Yellow toner) x 1 10K MX-23GT-YA 10
Developer (Black) Developer (Black developer) x 1 840K
rotaion
MX-36GV-BA 10 Standard Printable number
23cpm 100K(BK) / 80K(CL)
26cpm 120K(BK) / 120K(CL)
31cpm 135K(BK) / 120K(CL)
Maximum Printable number
23cpm 120K(BK) / 100K(CL)
26cpm 140K(BK) / 140K(CL)
31cpm 155K(BK) / 140K(CL)
Developer
(Cyan/Magenta/
Yellow: 3 colors/set)
Developer
(Cyan/Magenta/Yellow: 3 colors/set)
(Developer (each colors))
x 1 840K
rotaion
MX-36GV-SA 10
Drum OPC drum x 1 840K
rotaion
MX-36GR-SA 10
Drum unit OPC drum unit (Process unit + OPC drum)
Color identification seal (B/C/M/Y) x 1 each
Charger cleaner
x 1
x 1
x 1
840K
rotaion
MX-36GU-SA 10
Item Content Life Model name
Quantity in
collective
package
Remarks
Toner cartridge
(Black)
Toner cartridge (Black toner) x 1 18K MX-23AT-BA 10 * Life: A4/Letter size at area
coverage 5%
(Reference: 15K for A4/Letter
6%)
Toner cartridge
(Cyan)
Toner cartridge (Cyan toner) x 1 10K MX-23AT-CA 10 * Life: A4/Letter size at area
coverage 5%
Toner cartridge
(Magenta)
Toner cartridge (Magenta toner) x 1 10K MX-23AT-MA 10
Toner cartridge
(Yellow)
Toner cartridge (Yellow toner) x 1 10K MX-23AT-YA 10
Developer (Black) Developer (Black developer) x 1 840K
rotaion
MX-36AV-BA 10
Standard Printable number
23cpm 100K(BK) / 80K(CL)
26cpm 120K(BK) / 120K(CL)
31cpm 135K(BK) / 120K(CL)
Maximum Printable number
23cpm 120K(BK) / 100K(CL)
26cpm 140K(BK) / 140K(CL)
31cpm 155K(BK) / 140K(CL)
Developer
(Cyan/Magenta/
Yellow: 3 colors/set)
Developer
(Cyan/Magenta/Yellow: 3 colors/set)
(Developer (each colors))
x 1 840K
rotaion
MX-36AV-SA 10
Drum OPC drum x 1 840K
rotaion
MX-36AR-SA 10
Drum unit OPC drum unit (Process unit + OPC drum)
Color identification seal (B/C/M/Y) x 1 each
Charger cleaner
x 1
x 1
x 1
840K
rotaion
MX-36AU-SA 10

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
