Sharp MX-2314N Service Manual

MX-3114N SPECIFICATIONS 2 – 6
B. Copy functions
(1) First copy time
(2) Job Speed
C. Printer function
(1) Printer driver supported OS
(2) PDL emulation/Font
D. FAX function
(1) Transmission method
(2) Number of Support Line
(3) Transmission Mode
(4) Image Quality/Image Process
(5) Record Size
* If the document length exceeds A3 size, it is divided and printed.
* For printing the list, A5R and 8.5 x 5.5R cannot be used.
Engine
23cpm machine 26cpm machine 31cpm machine
Mono-chrome Color Mono-chrome Color Mono-chrome Color
Platen 7.4 sec. 10.0 sec. 5.9 sec. 8.1 sec. 5.8 sec. 7.9 sec.
RSPF 10.0 sec. 13.2 sec. 9.1 sec. 11.6 sec. 9.1 sec. 11.6 sec.
Engine
23cpm machine 26cpm machine 31cpm machine
Mono-chrome Color Mono-chrome Color Mono-chrome Color
S to S 23cpm (100%) 23cpm (100%) 26cpm (100%) 26cpm (100%) 31cpm (100%) 31cpm (100%)
OS Custom PCL6 Custom PS PPD
Sharp Advanced
Printing Language
PC-FAX
Windows XP CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
XP (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Server 2003 CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Server 2003 (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Server 2012 (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Vista CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Vista (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Server 2008 CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Server 2008 (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Windows 7 CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Windows 7 (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Windows 8 CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Windows 8 (x 64) CD-ROM CD-ROM CD-ROM CD-ROM CD-ROM
Mac X 10.4 No No CD-ROM No No
X 10.5 No No CD-ROM No Web
X 10.6 No No CD-ROM No Web
X 10.7 No No CD-ROM No Web
X 10.8 No No CD-ROM No Web
PDL (Command) Installed font Option font
PCL6 compatibility STD European outline font = 80 styles
Line printer font (BMP) = 1 style
Barcode font = 28 styles
Postscript3 compatibility OPT - European outline font = 136 styles
Transmission time Less than 3 sec (Super G3)
Less than 7 sec (G3 ECM)
Compression/
expansion system
MH, MR, MMR, JBIG
(Fixed to ECM for MMR or JBIG.)
Modem speed 33.6kbps → 2.4kbps automatic fallback
Resolution 8 x 3.85 line/mm, 8 x 7.7 line/mm,
8.15.4 line/mm, 16 x 15.4 line/mm (Standard
memory is used for transmit/receive.)
Intercommunication G3/Super G3: Standard (V.34, V.17, V.33, V.29,
V.27ter)
Communication line General telephone line (PSTN), ISDN (When TA
is installed.) Private Branch Exchange (PBX)
ECM Yes
Standard 1 line
Expansion Not provided
RSPF/OC
transmission switching
Yes (Switching during the reading is not feasible)
Half tone reproduction Equivalent to 256 levels (Valid only when
monochrome document is scanned.)
Exposure adjustment Auto / Manual (5 steps)
FAX quality selection Standard (8 x 3.85 lines/mm (203.2 x 97.8dpi))
Fine (8 x 7.7 lines/mm (203.2 x 195.6dpi))
Super Fine (8 x 15.4 lines/mm (203.2 x 391dpi))
Ultra Fine (16 x 15.4 lines/mm (406.4 x 391dpi))
Half-tone (Combination with normal character is
invalid.)
Max. record width 293mm
Record size (AB series)
A3, B4, A4, A4R, B5, B5R, A5R
(Inch series)
11 x 17, 8.5 x 13, 8.5 x 14, 8.5 x 11, 8.5 x 11R,
8.5 x 5.5R

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
