MX-3114N DISASSEMBLY AND ASSEMBLY 10 – 1
MX-3114N
Service Manual
[10] DISASSEMBLY AND ASSEMBLY
1. Disassembly of Units
A. External view
(1) Front cabinet upper
1) Remove the front cabinet upper.
(2) Rear upper cabinet
1) Remove the rear upper cabinet.
(3) Rear cabinet
1) Remove the rear cabinet.
No. Name
1 Front cabinet upper
2 Rear upper cabinet
3 Rear cabinet
4 Left cabinet
5 Shield plate
6 Paper exit cover
7 Left cabinet upper
8 Paper exit tray
9 Upper cabinet left
10 Upper cabinet right
11 ROM cover
12 Ozone filter cover



