MX-3114N VARIOUS STORAGE DATA HANDLING 11 – 1
MX-3114N
ServiceManual
[11] VARIOUS STORAGE DATA HANDLING
1. HDD/SD card memory map
A. HDD partition
HDD size = 320GB (Actual size 289GB)
B. HDD data contents
No. File system Stored data NOTE
I-1 Image data Image data (ERDH/Temporary storage) 1000 documents, 10000 images
I-2 Image data Image data (Document filing) 3000 documents, 20000 images
I-3 Image data Not available Not used
I-4 Image data FAX/Internet Fax receive images
L-1 Not available System storage data (Address book, image send system registration data)
S-0 Universal System setting value data (for backup)
S-1 Universal
Download font
User profile
User macro
Database system file
S-2 Universal
Document filing (database)
Job log(database)
Job completion list
S-3 Universal System log
S-4 Universal Not available Not used
S-5 Universal Spool area for printer
S-6 Universal Application work area (user file used in SMB direct print)
S-7 Universal eOSA application file
S-8 Universal User file saved in the SMB server
S-9 Universal Data backup when installing DSK (address book, account information)
S-10 Universal
e-manual
watermark
L-2 Not available Not used
