Sharp MX-2314N Service Manual

MX-3114N MAINTENANCE 9 – 22
D. OPC drum section
Unit name
Parts work
sequence
Part name When calling 840 K rotation 840 K rotation 840 K rotation Remark
OPC drum unit
(monochrome)
1Drum
✕
840K rotation or
Maximum printable
number
23cpm:120K(BK)/
100K(CL)
26cpm:140K(BK)/
140K(CL)
31cpm:155K(BK)/
140K(CL)
2MC unit
✕

3 Cleaning blade
✕

4 Toner reception
blade
✕✕✕✕
5 Side seals
F/R
✕✕✕✕
6 Charger
cleaner
✕ 
OPC drum unit (color) 1 Drum
✕

2MC unit
✕

3 Cleaning blade
✕

4 Toner reception
blade
✕✕✕✕
5 Side seals
F/R
✕✕✕✕
6 Charger
cleaner
✕ 
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ
1
6
4
5
5
2
3
