Sharp MX-2314N - Waste Toner Box

MX-3114N MAINTENANCE 9 – 3
E. OPC drum
* After execution of the maintenance, execute SIM24-4 to clear the OPC drum print counter, the accumulated number of rotations counter, and
the use day counter.
F. Developer
* After execution of the maintenance, execute SIM24-4 to clear the developer print counter, the accumulated number of rotations counter, and
the use day counter.
G. Waste toner box
* When the waste toner box is replaced with an empty one, the message disappears.
H. Toner
Display content
Display condition
Print JOB
Enable/Disable
SIM26-38-A
set value
Counter name Counter value
Maintenance required.: DK 0 (Print continue) OPC drum print counter (K)
or
OPC drum accumulated rotation number counter (K)
840 rotation or
23cpm:120K
26cpm:140K
31cpm:155K
Enable
1 (Print stop)
Maintenance required.: D (C/M/Y) 0 (Print continue) OPC drum print counter (C/M/Y)
or
OPC drum accumulated rotation number counter
(C/M/Y)
840 rotation or
23cpm:100K
26cpm:140K
31cpm:140K
1 (Print stop)
Display content
Display condition
Print JOB
Enable/Disable
SIM26-38-A
set value
Counter name Counter value
Maintenance required.: DK 0 (Print continue) OPC drum print counter (K)
or
OPC drum accumulated rotation number counter (K)
840 rotation or
23cpm:120K
26cpm:140K
31cpm:155K
Enable
1 (Print stop)
Maintenance required.: D (C/M/Y) 0 (Print continue) OPC drum print counter (C/M/Y)
or
OPC drum accumulated rotation number counter
(C/M/Y)
840 rotation or
23cpm:100K
26cpm:140K
31cpm:140K
1 (Print stop)
Display content
Display condition
Print JOB
Enable/Disable
Counter name Counter value
Check the waste toner box. After detection of near end, pixel count 836K
(equivalent to color 2K, monochrome 8K print)
Near end: Enable
End: Disable
Display content
Display condition
Print JOB
Enable/Disable
SIM26-38-A
set value
Counter name Counter value
(K/C/M/Y) Prepare a toner
(Near near end)
No relation Toner motor rotation time Specified time of rotations Enable
(K/C/M/Y) Toner supply is low
(Near end)
No relation Toner supply amount is decreasing. ATC sensor output variation Enable
Replace the toner cartridge. (K)
(End)
0 (Print continue) The pixel count from near end
reaches the specified value.
Specified pixel count (Disable for a JOB which
requires K toner)
1 (Print stop)
Replace the toner cartridge.
(C/M/Y) (End)
0 (Print continue) The pixel count from near end
reaches the specified value.
Specified pixel count Enable for monochrome,
Disable for color
1 (Print stop)
