Sharp MX-2314N Service Manual

MX-3114N MAINTENANCE 9 – 2
2. Display of maintenance execution timing
The message of maintenance execution timing is displayed when each counter reaches the set value. The relations between the messages
and the counters are shown below.
A. Maintenance counter
* After execution of maintenance, be sure to execute SIM24-4 to clear the maintenance counter (Total) and the maintenance counter (Color).
B. Primary transfer unit
* After execution of the maintenance, execute SIM24-4 to clear the primary transfer unit print counter, the accumulated number of rotations
counter, and the use day counter.
C. Secondary transfer unit
* After execution of the maintenance, execute SIM24-4 to clear the secondary transfer print counter, the accumulated number of rotations
counter, and the use day counter.
D. Fusing unit
* After execution of the maintenance, execute SIM24-4 to clear the fusing roller counter, the fusing belt counter, the fusing web print counter,
the accumulated rotation number counter, and the use day counter.
Display content
Display condition
Print JOB
Enable/
Disable
SIM26-38-A
set value
Counter name Counter value
Maintenance required. Code: TA 0 (Print continue) Maintenance counter (Total) When the SIM21-1 set value is reached. Enable
1 (Print stop) When 90% of the SIM21-1 set value is reached.
Maintenance required. Code: TA 1 (Print stop) When the SIM21-1 set value is reached. Disable
Maintenance required. Code: CA 0 (Print continue) Maintenance counter (Color) When the SIM21-1 set value is reached. Enable
1 (Print stop) When 90% of the SIM21-1 set value is reached.
Maintenance required. Code: CA 1 (Print stop) When the SIM21-1 set value is reached. Disable
Maintenance required. Code: AA 0 (Print continue) Both of total and color When the SIM21-1 set value is reached. Enable
1 (Print stop) When 90% of the SIM21-1 set value is reached.
Maintenance required. Code: AA 1 (Print stop) When the SIM21-1 set value is reached. Disable
Display content
Display condition
Print JOB
Enable/
Disable
SIM26-38-A
set value
Counter name Counter value
Maintenance required.: TK1 0 (Print continue) Primary transfer unit print counter 23cpm : 100K
26/31cpm : 200K
Enable
1 (Print stop)
Display content
Display condition
Print JOB
Enable/
Disable
SIM26-38-A
set value
Counter name Counter value
Maintenance required.: TK2 0 (Print continue) Secondary transfer unit print counter 300K Enable
1 (Print stop)
Display content
Display condition
Print JOB
Enable/
Disable
SIM26-38-A
set value
SIM26-38-B
set value
Counter name Counter value
Maintenance required.: FK1 0 (Print continue) – Fusing belt print counter 23cpm : 100K
26/31cpm : 200K
Enable
1 (Print stop) –
Maintenance required.: FK2 0 (Print continue) – Pressure roller print counter 200K Enable
1 (Print stop) –
Maintenance required.: FK3 – 0 (Print continue) Fusing web print counter 26/31cpm : 200K Enable
– 1 (Print stop)
Maintenance required.: FK3 (Pop-up) – 0 (Print continue) Fusing web print counter When Web end detection is ON. Enable
– 1 (Print stop) Disable
