Sharp MX-2314N Service Manual

MX-3114N CONSUMABLE PARTS 3 – 2
(3) Middle East, Africa, Taiwan, Israel, Phillipines
2. Maintenance parts list
A. 23cpm machine
(1) Europe, Eastern Europe, Russia, Australia, New Zealand, Taiwan
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
Item Content Life Model name
Quantity in
collective
package
Remarks
Toner cartridge
(Black)
Toner cartridge (Black toner) x 1 18K MX-23FT-BA 10 * Life: A4/Letter size at area
coverage 5%
(Reference: 15K for A4/Letter
6%)
Toner cartridge
(Cyan)
Toner cartridge (Cyan toner) x 1 10K MX-23FT-CA 10 * Life: A4/Letter size at area
coverage 5%
Toner cartridge
(Magenta)
Toner cartridge (Magenta toner) x 1 10K MX-23FT-MA 10
Toner cartridge
(Yellow)
Toner cartridge (Yellow toner) x 1 10K MX-23FT-YA 10
Developer (Black) Developer (Black developer) x 1 840K
rotaion
MX-36FV-BA 10 Standard Printable number
23cpm 100K(BK) / 80K(CL)
26cpm 120K(BK) / 120K(CL)
31cpm 135K(BK) / 120K(CL)
Maximum Printable number
23cpm 120K(BK) / 100K(CL)
26cpm 140K(BK) / 140K(CL)
31cpm 155K(BK) / 140K(CL)
Developer
(Cyan/Magenta/
Yellow: 3 colors/set)
Developer
(Cyan/Magenta/Yellow: 3 colors/set)
(Developer (each colors))
x 1 840K
rotaion
MX-36FV-SA 10
Drum OPC drum x 1 840K
rotaion
MX-36FR-SA 10
Drum unit OPC drum unit (Process unit + OPC drum)
Color identification seal (B/C/M/Y) x 1 each
Charger cleaner
x 1
x 1
x 1
840K
rotaion
MX-36FU-SA 10
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Fusing belt kit MX-361FB Fusing belt x 1 100K 10
Fuser belt guide collar x 2
Pressure roller kit MX-230LH Fusing roller x 1 200K 10
Pressure roller x 1
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
Filter kit MX-361FL Ozone filter x 1 300K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for
each color; 25%
color ratio
Main charger kit MX-230MK Main charger unit
Cleaning gum AS AR
Cleaning blade AR
x 1
x 1
x 1
Drum
840K
Rotation
10
Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times
x 3
20 For MX-FN17
Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-231FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
Fusing unit MX-231FU2 Fusing unit (For service rotation : Heater lamp 110V) x 1 — 1

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
