Sharp MX-2314N Service Manual

MX-3114N MAINTENANCE 9 – 47
(6) Punch unit
Parts work
sequence
Part name
When
calling
At the
machine cycle
Remark
1 Punch unit ✕✕Replacement reference: Replace the unit at every 1000K.
2 Sensors ✕✕
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ
2
2
2
1
