MX-3114N MAINTENANCE 9 – 46
(5) Finisher
Parts work
sequence
Part name
When
calling
At the
machine cycle
Remark
1 Staple cartridge ✕✕Replacement is made by the user at every 5,000 pcs.
2 Staple unit ✕✕Replacement reference: Replace the unit at every 200K staple.
3 Paddle ✕ 
4 Inlet port paper transport roller ✕ 
5 Inlet port paper transport roller B ✕ 
6 Discharge brush ✕✕
7 Paper exit roller B ✕ 
8 Paper exit roller ✕ 
9 Bundle exit paper transport roller ✕ 
10 Bundle exit paper exit transport roller B ✕ 
11 Scraping roller ✕  Replacement reference: Replace at every 1000K of the finisher paper exit
count value.
12 Sensors ✕✕
– Paper guides ✕  Clean with alcohol.
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ
3
12
12
12
6
1
2
3
4
8
7
11
12
5
10
9
7
8
5
