MX3114N TROUBLESHOOTING 7 – 35
(3) Inner finisher
3. Image send communication report code
A. Outline and code system descriptions
After completion of communication, the communication report
table, the communication management table, and the protocol are
described on the communication report column.
The communication report code is composed as follows:
Communication report: XX (XXXX)
The upper 2 digits of the communication report code:
Communication report code of 00 – 99 (Refer to communication
report main code.)
The lower 4 digits of the communication report code:
Used by the serviceman.
The upper 2 digits: Communication report sub code 1 (Refer to
communication report sub code 1.)
The lower 2 digits: Communication report sub code 2 (Refer to
communication report sub code 2.)
The communication report sub code 1 and sub code 2 are in hexa-
decimal notation. (The others are in decimal notation.)
The communication report sub code 1 is not used in the these mod-
els.
B. Details
(1) Communication report main code
For report codes 16 – 31, V.34 MODE COMMUNICATION.
DPFD2_S4 DPFD2 remaining JAM (Desk 2 feed paper) D2PPD ON D2PPD does not turn OFF within the specified time.
TRAY4 Casette 4 (Desk 2) paper feed JAM D2PFC ON (Paper feed start) D2PPD does not turn ON within the specified time.
JAM code JAM content
JAM detection method
JAM detection start trigger JAM judgment condition
JAM code JAM content
JAM detection method
Basic distance
(A) [mm]
JAM margin
distance (B)
[mm]
JAM detection
distance (A+B)
[mm]
JAM detection start
trigger
JAM judgment condition
FPPD1_N Finisher inlet port
not-reached JAM
Machine paper exit
command reception
FPPD1 does not turn ON within the
specified time.
134.602 [mm] 400 [mm] 534.602 [mm]
FPPD1_S Finisher inlet port
remaining JAM
(When Long-size paper
support OFF)
FPPD1 ON FPPD1 does not turn OFF within
the specified time.
464.803 [mm] 50 [mm] 514.803 [mm]
Finisher inlet port
remaining JAM
(When Long-size paper
support ON)
FPPD1 ON FPPD1 does not turn OFF within
the specified time.
1207.803 [mm] 50 [mm] 1257.803 [mm]
FPDD_S Bundle exit remaining
JAM
Driving the bundle exit
roller is started.
FSTPD does not turn OFF within
the specified time.
133.1 [mm] 13.66 [mm] 146.76 [mm]
FIN_TIME Finisher paper early
reaching JAM
FPPD1 ON by the
prior paper detection
FPPD1 of the next paper turns ON
at the timing earlier than the
specified paper interval.
Specified paper
interval time
30 [mm] (Paper interval
time) - (Paper
transport time
of 30 [mm])
[msec]
FSTPD_S Finisher paper exit
remaining JAM
Driving the paper exit
roller in the straight
mode is started.
FSTPD does not turn OFF within
the specified time.
96.76 [mm] 50 [mm] 146.76 [mm]
FSTPLJ Staple JAM FSHPS OFF after
FSM ON
FSHPS does not turn ON within the
specified time.
350 [msec] 250 [msec] 600 [msec]
Report
code
Final receive signal
(Send side)
Final receive signal (Receive side)
0 Abnormal signal Abnormal signal
1 NSF, DIS (SID), (SUB), NSS, DCS
2 CFR (PWD), (SEP), NSC, DTC
3 FTT EOP
4MCF EOM
5 PIP, PIN MPS
6RTN, RTP PRI-Q
7 No signal, DCN DCN
8 PPR PPS-EOP
9PPS-EOM
10 PPS-MPS, PPS-NULL
11 RNR RR
12 CTR CTC
13 ERR EOR-Q
14 PPS-PRI-Q
16 Abnormal signal Abnormal signal
17 NSF, DIS SID, SUB, NSS, DCS
18 CFR PWD, SEP, NSC, DTC
19 FTT PPS-EOP
20 MCF PPS-EOM
21 PIP, PIN PPS-MPS, PPS-NULL
22 RTN, RTP PRI-Q
23 No signal, DCN DCN
24 PPR
25 RNR RR
26 CTR CTC
27 ERR EOR-Q
28 PPS-PRI-Q
29 V.8 Phase-1 V.8 Phase-1
30 V.8 Phase-2 V.8 Phase-2
31 V.8 Phase-3 V.8 Phase-3
Report
code
Final receive signal
(Send side)
Final receive signal (Receive side)
To Next Page
