Sharp MX-2314N Service Manual

MX3114N TROUBLESHOOTING 7 – 34
(1) RSPF
(2) Desk
PPD2_FIN PPD2 JAM
(Finisher communication
abnormality detection)
Transmission of the paper
attribute data command to
FINISHER
Reception time-out of the
paper interval data command
from FINISHER (30 sec)
—— —
JAM code JAM content
JAM detection method
Basic
distance (A)
[mm]
JAM margin
distance (B)
[mm]
JAM
detection
distance
(A+B) [mm]
JAM detection start trigger JAM judgment condition
JAM code JAM content
JAM detection method
Basic distance
(A) [mm]
JAM margin
distance (B)
[mm]
JAM detection
distance (A+B)
[mm]
JAM detection start trigger JAM judgment condition
SPPD1_N SPPD1 not-reached
JAM
Paper feed start
(When the document width is
more than B5 size.)
SPPD1 ON 51.5 450.0 501.5
SPPD2_N SPPD2 not-reached
JAM
Paper feed start
(When the document width is
less than B5 size.)
SPPD2 ON 90.2 450.0 540.2
SPPD1 ON
(When the document width is
more than B5 size.)
SPPD2 ON 38.7 50.0 88.7
SPPD3_N SPPD3 not-reached
JAM
Restart at the temporal stop
position
SPPD3 ON 23.7 50.0 73.7
SPPD4_N SPPD4 not-reached
JAM
SPPD3 ON SPPD4 ON 149.1 50.0 199.1
SPPD2_NR SPPD2 reverse not-
reached JAM
Reversing start SPPD2 ON 85.5 50.0 135.5
SPPD1_S SPPD1 remaining
JAM
SPPD1 ON
(When the document width is
more than B5 size.)
SPPD1 OFF Normal mode:
431.8mm
Long size mode:
1000mm/
800mm (23cpm
model 600dpi
mode)
50.0 Normal mode:
481.8mm
Long size mode:
1050mm/
850mm (23cpm
model 600dpi
mode)
SPPD2_S SPPD2 remaining
JAM
SPPD2 ON
(When the document width is
less than B5 size.)
SPPD2 OFF Normal mode:
431.8mm
Long size mode:
1000mm/
800mm (23cpm
model 600dpi
mode)
50.0 Normal mode:
481.8mm
Long size mode:
1050mm/
850mm (23cpm
model 600dpi
mode)
SPPD1 OFF
(When the document width is
more than B5 size.)
SPPD2 OFF 37.8 50.0 87.8
SPPD3_S SPPD3 remaining
JAM
SPPD2 OFF SPPD3 OFF 68.8 50.0 118.8
SPPD4_S SPPD4 remaining
JAM
SPPD3 OFF SPPD4 OFF 153.3 50.0 203.3
SPPD2_SR SPPD2 reverse
remaining JAM
SPPD4 OFF SPPD2 OFF 100.9 50.0 150.9
SPSD_SCN Exposure start
notification timer end
Arrival at temporal stop
position
Exposure start command from
ICU to SCU no reception time-
out (120 sec)
———
P_SHORT Short size JAM SPPD3 ON When the document length is
less than 120.0mm.
———
SDFS_S Paper JAM Start of the light quantity
correction between papers
When canceling of the light
quantity correction between
papers does not make it in
time.
———
ICU_REQ ICU factor stop JAM — Stop by a job stop request
commend from ICU to SCU
———
STOP_JAM Emergency stop JAM — Trouble mode transition
request from ICU to SCU
Emergency stop by a
command
———
JAM code JAM content
JAM detection method
JAM detection start trigger JAM judgment condition
TRAY3 Casette 3 (Desk 1) paper feed JAM D1PFC ON (Paper feed start) D1PPD does not turn ON within the specified time.
DPFD1_N4 DPFD1 not-reached JAM (Desk 2 feed paper) D2PPD ON D1PPD does not turn ON within the specified time.
DPFD1_S3 DPFD1 remaining JAM (Desk 1 feed paper) D1PPD ON D1PPD does not turn OFF within the specified time.
DPFD1_S4 DPFD1 remaining JAM (Desk 2 feed paper) D2PPD OFF D1PPD does not turn OFF within the specified time.

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
