MX-3114N SIMULATION 6 – 51
43-23
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under high temperature and high humidity
(H/H) for the fusing temperature setting
(SIM 43-4) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Correction value: -49 - +49, Input value: Actually inputted value (1 -
99)
* Items PLAIN BW DUP APP CNT HH/ PLAIN CL DUP APP CNT HH: 1 Count = 1s Change
Correction value for the other items: 1 count for 1C change
Code descriptions
Correction value -49 -25 -5 0
Input value 1 25 45 50
Item/Display Content
Setting
range
Default
value
A HL_UM PLAIN BW DUP HH Correction value for TH_UM Black-White plain paper duplex mode under HH environment 1 - 99 50
B HL_LM PLAIN BW DUP HH Correction value for TH_LM Black-White plain paper duplex mode under HH environment 1 - 99 50
C HL_US PLAIN BW DUP HH Correction value for TH_US Black-White plain paper duplex mode under HH environment 1 - 99 50
D PLAIN BW DUP APP CNT HH Correction value for applying number of sheets in Black-White plain paper duplex under HH
environment
1 - 99 50
E HL_UM PLAIN CL DUP HH Correction value for TH_UM Color plain paper duplex mode under HH environment 1 - 99 50
F HL_LM PLAIN CL DUP HH Correction value for TH_LM Color plain paper duplex mode under HH environment 1 - 99 50
G HL_US PLAIN CL DUP HH Correction value for TH_US Color plain paper duplex mode under HH environment 1 - 99 50
H PLAIN CL DUP APP CNT HH Correction value for applying number of sheets in Color plain paper duplex under HH environment 1 - 99 50
I HL_UM HEAVY BW DUP HH Correction value for Black-White heavy paper duplex mode TH_UM set value under HH environment 1 - 99 50
J HL_LM HEAVY BW DUP HH Correction value for Black-White heavy paper duplex mode TH_LM set value under HH environment 1 - 99 50
K HL_US HEAVY BW DUP HH Correction value for Black-White heavy paper duplex mode TH_US set value under HH environment 1 - 99 50
L HEAVY BW DUP APP CNT HH Correction value for applying number of sheets in Black-White heavy paper duplex under HH
environment
1 - 99 50
M HL_UM HEAVY CL DUP HH Correction value for Color heavy paper duplex mode TH_UM set value under HH environment 1 - 99 50
N HL_LM HEAVY CL DUP HH Correction value for Color heavy paper duplex mode TH_LM set value under HH environment 1 - 99 50
O HL_US HEAVY CL DUP HH Correction value for Color heavy paper duplex mode TH_US set value under HH environment 1 - 99 50
P HEAVY CL DUP APP CNT HH Correction value for applying number of sheets in Color heavy paper duplex under HH environment 1 - 99 50
TH_UM Fusing thermistor main (Front surface of paper) HL_UM Heater lamp main (Heat roller for front surface of paper)
TH_LM Fusing thermistor main (Back surface of paper) HL_LM Heater lamp main (Heat roller for back surface of paper)
TH_US Fusing thermistor sub (Front surface of paper) HL_US Heater lamp sub (Heat roller for front surface of paper)
