Sharp MX-2314N Service Manual

MX-3114N SIMULATION 6 – 50
List of destination groups
43-22
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under low temperature and low humidity (L/
L) for the fusing temperature setting (SIM
43-4) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2 is saved.
Correction value: -49 - +49, Input value: Actually inputted value (1 -
99)
* Items PLAIN BW DUP APP CNT LL/ PLAIN CL DUP APP CNT LL: 1 Count = 1s Change
Correction value for the other items: 1 count for 1C change
Code descriptions
TH_LM Fusing thermistor main (Back surface of paper) HL_LM Heater lamp main (Heat roller for back surface of paper)
TH_US Fusing thermistor sub (Front surface of paper) HL_US Heater lamp sub (Heat roller for front surface of paper)
Group
Destination
Group A JAPAN
- - - - -
Group B U.S.A CANADA INCH
- - -
Group C AB_B
EUROPE
U.K. AUS. AB_A CHINA
Correction value -49 -25 -5 0
Input value 1 25 45 50
Item/Display Content
Setting
range
Default
value
A HL_UM PLAIN BW DUP LL Correction value for upper TH_UM Black-White plain paper duplex under LL environment 1 - 99 55
B HL_LM PLAIN BW DUP LL Correction value for lower TH_LM Black-White plain paper duplex under LL environment 1 - 99 55
C HL_US PLAIN BW DUP LL Correction value for upper TH_US Black-White plain paper duplex under LL environment 1 - 99 55
D PLAIN BW DUP APP CNT LL Correction value for applying number of sheets in Black-White plain paper duplex under LL
environment
1 - 99 50
E HL_UM PLAIN CL DUP LL Correction value for upper TH_UM Color plain paper duplex under LL environment 1 - 99 55
F HL_LM PLAIN CL DUP LL Correction value for lower TH_LM Color plain paper duplex under LL environment 1 - 99 55
G HL_US PLAIN CL DUP LL Correction value for upper TH_US Color plain paper duplex under LL environment 1 - 99 55
H PLAIN CL DUP APP CNT LL Correction value for applying number of sheets in Color plain paper duplex under LL environment 1 - 99 50
I HL_UM HEAVY BW DUP LL Correction value for upper TH_UM set value in Black-White heavy paper duplex under LL
environment
1 - 99 55
J HL_LM HEAVY BW DUP LL Correction value for lower TH_LM set value in Black-White heavy paper duplex under LL environment 1 - 99 55
K HL_US HEAVY BW DUP LL Correction value for upper TH_US set value in Black-White heavy paper duplex under LL
environment
1 - 99 55
L HEAVY BW DUP APP CNT LL Correction value for applying number of sheets in Black-White heavy paper duplex under LL
environment
1 - 99 50
M HL_UM HEAVY CL DUP LL Correction value for upper TH_UM set value in Color heavy paper duplex under LL environment 1 - 99 55
N HL_LM HEAVY CL DUP LL Correction value for lower TH_LM set value in Color heavy paper duplex under LL environment 1 - 99 55
O HL_US HEAVY CL DUP LL Correction value for upper TH_US set value in Color heavy paper duplex under LL environment 1 - 99 55
P HEAVY CL DUP APP CNT LL Correction value for applying number of sheets in Color heavy paper duplex under LL environment 1 - 99 50
TH_UM Fusing thermistor main (Front surface of paper) HL_UM Heater lamp main (Heat roller for front surface of paper)
TH_LM Fusing thermistor main (Back surface of paper) HL_LM Heater lamp main (Heat roller for back surface of paper)
TH_US Fusing thermistor sub (Front surface of paper) HL_US Heater lamp sub (Heat roller for front surface of paper)

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
