Sharp MX-2314N Service Manual

MX-3114N SIMULATION 6 – 49
43-21
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under high temperature and high humidity
(H/H) for the fusing temperature setting
(SIM 43-2) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2 is saved.
Correction value: -49 - +49, Input value: Actually inputted value (1 -
99)
* Item WARMUP END TIME HH: 1 Count = 1s Change
Correction value for the other items: 1 count for 1C change
Code descriptions
Correction value -49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
Item/Display Content
Setting
range
Default value
Group
A
Group
B
Group
C
A HL_UM READY HH Correction value for TH_UM set value in Ready standby under HH environment 1 - 99 40 45 50
B HL_LM READY HH Correction value for TH_LM set value in Ready standby under HH environment 1 - 99 40 45 50
C HL_US READY HH Correction value for TH_US set value in Ready standby under HH environment 1 - 99 40 45 50
D HL_UM PLAIN BW HH Correction value for Black-White plain paper TH_UM set value under HH environment 1 - 99 40 45 50
E HL_LM PLAIN BW HH Correction value for Black-White plain paper TH_LM set value under HH environment 1 - 99 40 45 50
F HL_US PLAIN BW HH Correction value for Black-White plain paper TH_US set value under HH environment 1 - 99 40 45 50
G HL_UM PLAIN CL HH Correction value for Color plain paper TH_UM set value under HH environment 1 - 99 40 45 50
H HL_LM PLAIN CL HH Correction value for Color plain paper TH_LM set value under HH environment 1 - 99 40 45 50
I HL_US PLAIN CL HH Correction value for Color plain paper TH_US set value under HH environment 1 - 99 40 45 50
J WARMUP FUMON HL_US T
HH
Correction value for fusing motor pre-rotation start TH_US set value under HH
environment
1 - 99 50 50 50
K WARMUP FUMOFF HH Fusing motor prior rotation completion time under HH environment 1 - 99 50 50 50
L WARMUP END TIME HH Correction value for warm-up complete time under HH environment 1 - 99 50 50 50
M HL_UM HEAVY HH Correction value for heavy paper TH_UM set value under HH environment 1 - 99 50 50 50
N HL_LM HEAVY HH Correction value for heavy paper TH_LM set value under HH environment 1 - 99 50 50 50
O HL_US HEAVY HH Correction value for heavy paper TH_US set value under HH environment 1 - 99 50 50 50
P HL_UM OHP HH Correction value for OHP TH_UM set value under HH environment 1 - 99 50 50 50
Q HL_LM OHP HH Correction value for OHP TH_LM set value under HH environment 1 - 99 50 50 50
R HL_US OHP HH Correction value for OHP TH_US set value under HH environment 1 - 99 50 50 50
S HL_UM ENVELOPE HH Correction value for envelope TH_UM set value under HH environment 1 - 99 50 50 50
T HL_LM ENVELOPE HH Correction value for envelope TH_LM set value under HH environment 1 - 99 50 50 50
U HL_US ENVELOPE HH Correction value for envelope TH_US set value under HH environment 1 - 99 50 50 50
V HL_UM GLOSS HH Correction value for glossy paper TH_UM set value under HH environment 1 - 99 50 50 50
W HL_LM GLOSS HH Correction value for glossy paper TH_LM set value under HH environment 1 - 99 50 50 50
X HL_US GLOSS HH Correction value for glossy paper TH_US set value under HH environment 1 - 99 50 50 50
Y HL_UM E-STAR HH Correction value for preheating TH_UM set value under HH environment 1 - 99 40 45 50
Z HL_US E-STAR HH Correction value for preheating TH_US set value under HH environment 1 - 99 40 45 50
A
A
HL_UM PRE-JOB HH Correction value for the set value of TH_UM when restoring from preheating under HH
environment
1 - 99 40 45 50
A
B
HL_LM E-STAR HH Correction value for preheating TH_LM set value under HH environment 1 - 99 40 45 50
A
C
LO_WARMUP_TIME_HH Correction value for AF-AH applying time (timer from Ready complete) under HH
environment
1 - 99 50 50 50
A
D
HI_WARMUP_TIME HH Correction value for AJ-AL applying time (timer from Ready complete) under HH
environmentHH
1 - 99 50 50 50
A
E
HI_WU_FM_ON_TMP_HH Correction value for FM prior rotation start TH_US in Warm-Up at alpha C or above
under HH environment
1 - 99 50 50 50
A
F
HI_WU_END_TIME_HH Correction value for Warm-Up completion time in Warm-Up at alpha C or above under
HH environment
1 - 99 50 50 50
A
G
HI_WU_JOB_SET_TMP_H
H
Correction value for Job Enable TH_UM temperature in Warm-Up at alpha ?C or
above under HH environment
1 - 99 40 45 50
A
H
HI_WARMUP_BORDER_H
H
Correction value for the threshold value alpha applying SIM43-1-AN - AP under HH
environment
1 - 99 50 50 50
AI LO_WU_JOB_SET_TMP_H
H
Correction value for Job Enable TH_UM temperature in Warm-Up at alpha ?C or
below under HH environment
1 - 99 40 45 50
AJ JOBEND_FUMON_TIME
HH
Correction value for the after rotation time when completing a job under HH
environment
1 - 99 50 50 50
A
K
LO_WU_JOB_SET_TMP_B
W HH
Correction value (BW) for Job enable TH_UM temperature when Warm-Up at alpha C
o
r above under HH environment
1 - 99 40 45 50
TH_UM Fusing thermistor main (Front surface of paper) HL_UM Heater lamp main (Heat roller for front surface of paper)
