MX-3114N SIMULATION 6 – 48
43-20
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environmental correction
under low temperature and low humidity (L/
L) for the fusing temperature setting (SIM
43-2) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Correction value: -49 - +49, Input value: Actually inputted value (1 -
99)
* Item WARMUP END TIME LL: 1 Count = 1s Change
Correction value for the other items: 1 count for 1C change
* Item D, F: When B5 size, correction of "-5" is made for item D and item F.
* Item G, I: When B5 size, correction of "-5" is made for item G and item I.
Code descriptions
Correction value -49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
Item/Display Content Setting
range
Default
value
A HL_UM READY LL Correction value for TH_UM set value in Ready standby under LL environment 1 - 99 55
B HL_LM READY LL Correction value for TH_LM set value in Ready standby under LL environment 1 - 99 55
C HL_US READY LL Correction value for TH_US set value in Ready standby under LL environment 1 - 99 55
D HL_UM PLAIN BW LL Correction value for Black-White plain paper TH_UM set value under LL environment 1 - 99 55
E HL_LM PLAIN BW LL Correction value for Black-White plain paper TH_LM set value under LL environment 1 - 99 55
F HL_US PLAIN BW LL Correction value for Black-White plain paper TH_US set value under LL environment 1 - 99 55
G HL_UM PLAIN CL LL Correction value for Color plain paper TH_UM set value under LL environment 1 - 99 55
H HL_LM PLAIN CL LL Correction value for Color plain paper TH_LM set value under LL environment 1 - 99 55
I HL_US PLAIN CL LL Correction value for Color plain paper TH_US set value under LL environment 1 - 99 55
J WARMUP FUMON HL_US T LL Correction value for fusing motor pre-rotation start TH_US set value under LL environment 1 - 99 55
K WARMUP FUMOFF LL Fusing motor prior rotation completion time under LL environment 1 - 99 55
L WARMUP END TIME LL Correction value for warm-up complete time under LL environment 1 - 99 55
M HL_UM HEAVY LL Correction value for heavy paper TH_UM set value under LL environment 1 - 99 55
N HL_LM HEAVY LL Correction value for heavy paper TH_LM set value under LL environment 1 - 99 55
O HL_US HEAVY LL Correction value for heavy paper TH_US set value under LL environment 1 - 99 55
P HL_UM OHP LL Correction value for OHP TH_UM set value under LL environment 1 - 99 55
Q HL_LM OHP LL Correction value for OHP TH_LM set value under LL environment 1 - 99 55
R HL_US OHP LL Correction value for OHP TH_US set value under LL environment 1 - 99 55
S HL_UM ENVELOPE LL Correction value for envelope TH_UM set value under LL environment 1 - 99 55
T HL_LM ENVELOPE LL Correction value for envelope TH_LM set value under LL environment 1 - 99 55
U HL_US ENVELOPE LL Correction value for envelope TH_US set value under LL environment 1 - 99 55
V HL_UM GLOSS LL Correction value for glossy paper TH_UM set value under LL environment 1 - 99 55
W HL_LM GLOSS LL Correction value for glossy paper TH_LM set value under LL environment 1 - 99 55
X HL_US GLOSS LL Correction value for glossy paper TH_US set value under LL environment 1 - 99 55
Y HL_UM E-STAR LL Correction value for preheating TH_UM set value under LL environment 1 - 99 55
Z HL_US E-STAR LL Correction value for preheating TH_US set value under LL environment 1 - 99 55
AA HL_UM PRE-JOB LL Correction value for the set value of TH_UM when restoring from preheating under LL
environment
1 - 99 55
AB HL_LM E-STAR LL Correction value for preheating TH_LM set value under LL environment 1 - 99 55
AC LO_WARMUP_TIME_LL Correction value for AF-AH applying time (timer from Ready complete) under LL environment 1 - 99 50
AD HI_WU_TIME_LL Correction value for AJ-AL applying time (timer from Ready complete) under LL environment 1 - 99 50
AE HI_WU_FM_ON_TMP_LL Correction value for FM prior rotation start TH_UM in Warm-Up at alpha C or above under LL
environment
1 - 99 40
AF HI_WU_END_TIME_LL Correction value for Warm-Up completion time in Warm-Up at alpha C or above under LL
environment
1 - 99 50
AG HI_WU_JOB_SET_TMP_LL Correction value for Job Enable TH_UM temperature in at alpha C or above under LL
environment
1 - 99 55
AH HI_WARMUP_BORDER_LL Correction value for the threshold value alpha applying SIM43-1-AN - AP under LL
environment
1 - 99 50
AI LO_WU_JOB_SET_TMP_LL Correction value for Job Enable TH_UM temperature in at alpha C or below under LL
environment
1 - 99 55
AJ JOBEND_FUMON_TIME LL Correction value for the after rotation time when completing a job under LL environment 1 - 99 50
AK LO_WU_JOB_SET_TMP_BW LL
Correction value (BW) for Job enable TH_UM temperature when Warm-Up at
alpha C or above under LL environment
1 - 99 55
TH_UM Fusing thermistor main (Front surface of paper) HL_UM Heater lamp main (Heat roller for front surface of paper)
TH_LM Fusing thermistor main (Back surface of paper) HL_LM Heater lamp main (Heat roller for back surface of paper)
TH_US Fusing thermistor sub (Front surface of paper) HL_US Heater lamp sub (Heat roller for front surface of paper)
