MX-3114N SIMULATION 6 – 47
43-4
Purpose
Setting
Function (Purpose)
Used to set the fusing temperature 2 in
each mode. (Continued from SIM 43-2.)
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Code descriptions
List of destination groups
Item/Display Content
Setting
range
Default value (SW-A) Default value (SW-B)
Group
A
Group
B
Group
C
Group
A
Group
B
Group
C
A HL_UM PLAIN PAPER BW DUP Black-White plain paper duplex TH_UM set value 70 - 230 145 145 155 155 155 165
B HL_LM PLAIN PAPER BW DUP Black-White plain paper duplex TH_LM set value 30 - 200 110 115 115 115 125 125
C HL_US PLAIN PAPER BW DUP Black-White plain paper duplex TH_US set value 70 - 230 145 150 155 150 155 160
D PLAIN PAPER BW DUP APP CNT Black and white plain paper duplex applying
number of sheets
0 - 60000000
E HL_UM PLAIN PAPER CL DUP Color plain paper duplex TH_UM set value 70 - 230 145 150 155 160 165 165
F HL_LM PLAIN PAPER CL DUP Color plain paper duplex TH_LM set value 30 - 200 110 115 115 115 125 125
G HL_US PLAIN PAPER CL DUP Color plain paper duplex TH_US set value 70 - 230 145 150 155 155 165 165
H PLAIN PAPER CL DUP APP CNT Color plain paper duplex applying number of
sheets
0 - 60000000
I HL_UM HEAVY PAPER BW DUP Black-White heavy paper duplex TH_UM set
value
70 - 230 190 190 190 190 190 190
J HL_LM HEAVY PAPER BW DUP Black-White heavy paper duplex TH_LM set
value
30 - 200 120 120 120 120 120 120
K HL_US HEAVY PAPER BW DUP Black-White heavy paper duplex TH_US set
value
70 - 230 160 160 160 160 160 160
L HEAVY PAPER BW DUP APP
CNT
Black and white heavy paper duplex applying
number of sheets
0 - 60000000
M HL_UM HEAVY PAPER CL DUP Color heavy paper duplex TH_UM set value 70 - 230 190 190 190 190 190 190
N HL_LM HEAVY PAPER CL DUP Color heavy paper duplex TH_LM set value 30 - 200 120 120 120 120 120 120
O HL_US HEAVY PAPER CL DUP Color heavy paper duplex TH_US set value 70 - 230 160 160 160 160 160 160
P HEAVY PAPER CL DUP APP CNT Color heavy paper duplex applying number of
sheets
0 - 60000000
TH_UM Fusing thermistor main (Front surface of paper) HL_UM Heater lamp main (Heat roller for front surface of paper)
TH_LM Fusing thermistor main (Back surface of paper) HL_LM Heater lamp main (Heat roller for front surface of paper)
TH_US Fusing thermistor sub (Front surface of paper) HL_US Heater lamp sub (Heat roller for front surface of paper)
SW-A Setting value when plain paper is selected in the system setting/device setting/fusing control setting.
SW-B Set value when heavy paper is selected in the system setting/device setting/fusing control setting.
The set value displayed in this simulation differs depending on plain paper or heavy paper which is selected in the system setting/device setting/fusing
control setting.
(Example) When plain paper is selected in the system setting/device setting/fusing control setting, the value of SW-A is displayed.
Group Destination
Group AJAPAN–––––
Group B U. S. A CANADA INCH – – –
Group C EUROPE U. K AUS. AB_A AB_B CHINA
