Sharp MX-2314N Service Manual

MX-3114N SIMULATION 6 – 52
43-24
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the correction of the tempera-
ture adjustment value of SIM 43-2 and 43-
4.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2 is saved.
Correction value: -49 - +49, Input value: Actually inputted value (1 -
99)
23cpm
26cpm/31cpm
Correction value -49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
Item/Display Content Default value
Group A Group B Group
C
A NN_120_FUS_DUP_HL_UM Correction value for SIM43-4 itemA, E at 120C or below in NN warm-up 50 50 50
B NN_120_FUS_DUP_HL_LM Correction value for SIM43-4 itemB, F at 120C or below in NN warm-up 50 50 50
C LL_120_FUS_DUP_HL_UM Correction value for SIM43-22 item A, E at 120Cor below in LL warm up 50 50 50
D LL_120_FUS_DUP_HL_LM Correction value for SIM43-22 item B, F at 120C or below in LL warm up 50 50 50
E HH_120_FUS_DUP_HL_UM Correction value for SIM43-23 item A, E at 120C or below in HH warm up 50 50 50
F HH_120_FUS_DUP_HL_LM Correction value for SIM43-23 item B, F at 120C or below in HH warm up 50 50 50
G NN_120_FUS_DUP_CNT Fusing duplex paper exit count under NN environment 5 5 5
H LL_120_FUS_DUP_CNT Fusing duplex paper exit count under LL environment 10 10 10
I HH_120_FUS_DUP_CNT Fusing deplex paper exit count under HH environment 5 5 5
J COOL_DOWN_HEAVY Cool down time for heavy paper 5 5 5
K COOL_DOWN_OHP Cool down time for OHP 10 10 10
L COOL_DOWN_ENVELOPE Cool down time for envelope 15 15 15
M NN_120_FUS_DUP_HL_US Correction value for SIM43-4 item C, G at 120C or below in NN warm up 50 50 50
N LL_120_FUS_DUP_HL_US Correction value for SIM43-22 item C, G at 120C or below in LL warm up 50 50 50
O HH_120_FUS_DUP_HL_US Correction value for SIM43-23 item C, G at 120C or below in HH warm up 50 50 50
P HL_UM THIN PAPER BW Thin paper BW-TH_UM 115 115 115
Q HL_LM THIN PAPER BW Thin paper BW-TH_LM 105 105 105
R HL_US THIN PAPER BW This paper BW-TH_US 125 125 125
S HL_UM THIN PAPER CL Thin paper COL-TH_UM 115 115 115
T HL_LM THIN PAPER CL This paper COL-TH_LM 105 105 105
U HL_US THIN PAPER CL Thin paper COL-TH_US 125 125 125
V HL_UM THIN PAPER READY Thin paper Ready-TH_UM 120 120 120
W HL_UM REC PAPER BW Recycled paper BW-TH_UM 130 135 135
X HL_LM REC PAPER BW Recycled paper BW-TH_LM 110 110 110
Y HL_US REC PAPER BW Recycled paper BW-TH_US 135 150 150
Z HL_UM REC PAPER CL Recycled paper COL-TH_UM 130 135 135
AA HL_LM REC PAPER CL Recycled paper COL-TH_LM 110 110 110
AB HL_US REC PAPER CL Recycled paper COL-TH_US 135 150 150
AC HL_UM REC PAPER READY Recycled paper Ready-TH_UM 140 145 145
Item/Display Content
Default value
Group A Group B Group C
A NN_120_FUS_DUP_HL_UM Correction value for SIM43-4-A, E at 120C or below in N/N Warm-Up 50 50 50
B NN_120_FUS_DUP_HL_LM Correction value for SIM43-4-B, F at 120C or below in N/N Warm-Up 50 50 50
C LL_120_FUS_DUP_HL_UM Correction value for SIM43-22-A, E at 120C or below in N/N Warm-Up 50 50 50
D LL_120_FUS_DUP_HL_LM Correction value for SIM43-22-B, F at 120C or below in N/N Warm-Up 50 50 50
E HH_120_FUS_DUP_HL_UM Correction value for SIM43-23-A, E at 120C or below in N/N Warm-Up 50 50 50
F HH_120_FUS_DUP_HL_LM Correction value for SIM43-23-B, F at 120C or below in N/N Warm-Up 50 50 50
G NN_120_FUS_DUP_CNT Fusing duplex paper exit count under NN environment 5 5 5
H LL_120_FUS_DUP_CNT Fusing duplex paper exit count under LL environment 10 10 10
I HH_120_FUS_DUP_CNT Fusing duplex paper exit count under HH environment 5 5 5
J COOL_DOWN_HEAVY Cool down time heavy paper 5 5 5
K COOL_DOWN_OHP Cool down time OHP 10 10 10
L COOL_DOWN_ENVELOPE Cool down time envelope 15 15 15
M FUSER MOTOR Web send quantity 10 10 10
N NN_120_FUS_DUP_HL_US Correction value for SIM43-4-C, G at 120C or below in N/N Warm-Up 50 50 50
O LL_120_FUS_DUP_HL_US Correction value for SIM43-22-C, G at 120C or below in L/L Warm-Up 50 50 50
P HH_120_FUS_DUP_HL_US Correction value for SIM43-23-C, G at 120C or below in H/H Warm-Up 50 50 50
Q HL_UM THIN PAPER BW Thin paper BW-TH_UM 135 135 135
R HL_LM THIN PAPER BW Thin paper BW-TH_LM 105 105 105
S HL_US THIN PAPER BW Thin paper BW-TH_US 135 135 135
T HL_UM THIN PAPER CL Thin paper COL-TH_UM 135 135 135
U HL_LM THIN PAPER CL Thin paper COL-TH_LM 105 105 105
