MX-3114N SIMULATION 6 – 53
* Each temperature correction value: 1 count for 1ï‚°C change in temperature control
* Each paper exit count: 1 count = 1 sheet change
* Each cool down time: 1 count = 1sec change
Code descriptions
List of destination groups
43-31
Purpose
Adjustment/Setup
Function (Purpose)
Used to check the operation of the fusing
web cleaning.
Section
Fusing
Operation/Procedure
1) Press [EXECUTE] key.
Cleaning the fusing web is performed.
2) When cleaning the fusing web is completed, "COMPLETE" is
displayed.
The set value may be changed for a design change or an individual
arrangement. Except for the above cases, however, the set value
must not be changed. If it is changed, a trouble may be occur.
43-32
Purpose
Adjustment/Setup
Function (Purpose)
Used to set various items related to the
forcible operation of web cleaning when job
end. (26/31 cpm machine)
Section
Fusing
Operation/Procedure
1) Select an item to be set with the scroll key.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
The set value may be changed for a design change or an individual
arrangement. Except for the above cases, however, the set value
must not be changed. If it is changed, a trouble may be occur.
V HL_US THIN PAPER CL Thin paper COL-TH_US 135 135 135
W HL_UM THIN PAPER READY Thin paper Ready-TH_UM 140 140 140
X HL_UM REC PAPER BW Recycled paper BW-TH_UM 150 155 160
Y HL_LM REC PAPER BW Recycled paper BW-TH_LM 110 110 110
Z HL_US REC PAPER BW Recycled paper BW-TH_US 140 155 165
AA HL_UM REC PAPER CL Recycled paper COL-TH_UM 150 155 160
AB HL_LM REC PAPER CL Recycled paper COL-TH_LM 110 110 110
AC HL_US REC PAPER CL Recycled paper COL-TH_US 140 155 165
AD HL_UM REC PAPER READY Recycled paper Ready-TH_UM 160 165 170
TH_UM Fusing thermistor main (Front surface of paper) HL_UM Heater lamp main (Heat roller for front surface of paper)
TH_LM Fusing thermistor main (Back surface of paper) HL_LM Heater lamp main (Heat roller for back surface of paper)
TH_US Fusing thermistor sub (Front surface of paper) HL_US Heater lamp sub (Heat roller for front surface of paper)
Group Destination
Group AJAPAN–––––
Group B U. S. A CANADA INCH – – –
Group C EUROPE U. K AUS. AB_A AB_B CHINA
Item/Display Content
Default value
Group A Group B Group C
Fusing web unit
installation
detection state
Operation Remarks
Fusing web unit not
installed
Does not operate * During this operation, the
fusing web cleaning feed
counter is counted up.
Fusing web unit
installed
Operates for the
specified time.
Item/Display Item
Setting
range
Default
value
A JOB END
COMP ACT
CHECK
Fusing web motor
forcible operation
condition when job end
Enable 0 - 1 0 1
Disable 1
B JOB END
COMP ACT
INTERVAL
Interval of the print quantity of
compulsory action of the fusing
web motor at job end
1 - 200 100
C JOB END
COMP ACT
CNT
Number of forcible operations of
the fusing web motor when job
end
1 - 5 1
