MX-3114N SIMULATION 6 – 21
22-13
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the operating time of the
process section (OPC drum, DV unit, toner
cartridge) and the fusing unit
Section
Process
Operation/Procedure
The number of prints and the number of rotations in the process
section are displayed.
22-14
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to display the use status of the toner
cartridge.
Section
Process
Operation/Procedure
The status of the toner cartridge is displayed.
Item/Display Content Print counter RPM
Number of
use days
Life meter
Number of
remaining
days
MAINTENANCE ALL Maintenance counter (Total) (Counter) Max. 8 Not displayed 0 - 999 0 - 100 (%) 0 - 365
MAINTENANCE COL Maintenance counter (Color) Max. 8 Not displayed 0 - 999 0 - 100 (%) 0 - 365
FUSING BELT Fusing belt Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
FUSING ROLLER Fusing roller Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
PRESSURE ROLLER Fusing pressure roller Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
FUSING LOAD Fusing pressure release roller Not displayed Max. 8 Not displayed Not displayed Not displayed
SEPARATE PAWL Fusing separation pawl Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
SEPARATE PLATE Fusing separation plate Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
FUSING WEB UNIT Fusing web unit Max. 8 Not displayed 0 - 999 0 - 100 (%) 0 - 365
FUSING WEB SEND Fusing web cleaning send counter 0 - 65535 Not displayed Not displayed Not displayed Not displayed
TC1 BELT Primary transfer belt Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
TRANSFER BLADE Transfer cleaning blade Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
PTC PTC Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
TC2 BELT Secondary transfer belt Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
PS PAPER Paper dust cleaner Max. 8 Not displayed 0 - 999 0 - 100 (%) 0 - 365
OZONE FILTER Ozone filter Max. 8 Not displayed 0 - 999 0 - 100 (%) 0 - 365
DEVE CTRG (K) DV unit (K) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DEVE CTRG (C) DV unit (C) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DEVE CTRG (M) DV unit (M) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DEVE CTRG (Y) DV unit (Y) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM CTRG (K) OPC drum unit (K) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM CTRG (C) OPC drum unit (C) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM CTRG (M) OPC drum unit (M) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM CTRG (Y) OPC drum unit (Y) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
MAIN CHARGER (K) Main charger (K) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
MAIN CHARGER (C) Main charger (C) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
MAIN CHARGER (M) Main charger (M) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
MAIN CHARGER (Y) Main charger (Y) Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM BLADE (K) OPC drum cleaning blade K Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM BLADE (C) OPC drum cleaning blade C Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM BLADE (M) OPC drum cleaning blade M Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
DRUM BLADE (Y) OPC drum cleaning blade Y Max. 8 Max. 8 0 - 999 0 - 100 (%) 0 - 365
TONER CTRG (K) Toner cartridge (K) Max. 8 Max. 8 0 - 999 0 - 100 (%) Not displayed
TONER CTRG (C) Toner cartridge (C) Max. 8 Max. 8 0 - 999 0 - 100 (%) Not displayed
TONER CTRG (M) Toner cartridge (M) Max. 8 Max. 8 0 - 999 0 - 100 (%) Not displayed
TONER CTRG (Y) Toner cartridge (Y) Max. 8 Max. 8 0 - 999 0 - 100 (%) Not displayed
Display item Content
Accumulated No. of
installed cartridges (Unit)
Accumulated No. of near
near end (Unit)
Accumulated No. of
end (Unit)
Remaining quantity
(Unit: %)
INSTALL NN END END RESIDUAL
TONER (K) Toner cartridge use counter (K) 0 - 255 0 - 255 0 - 255 0-25%
TONER (C) Toner cartridge use counter (C) 25-50%
TONER (M) Toner cartridge use counter (M) 50-75%
TONER (Y) Toner cartridge use counter (Y) 75-100%
