MX-3114N SIMULATION 6 – 23
22-42
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the JAM/trouble data
Section
Operation/Procedure
1) Select the item to be checked with the touch panel key.
2) Printable with [COLOR] and [MONO] keys.
22-43
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
JAM data details display
Section
Operation/Procedure
1) Select the item to be checked with the touch panel key.
When [COUNTER] key is pressed, the JAM counter, the paper
feed counter, and the paper feed retry counter are displayed.
When [HISTORY1] key is pressed, the JAM history is dis-
played.
When [HISTORY2] key is pressed, the temperature and
humidity data are displayed.
2) Printable with [COLOR] and [MONO] keys.
Display data and contents (COUNTER)
Display data and contents (HISTORY1)
*1: Refer to the detail display content of HISTORY1.
Display data and contents (HISTORY2)
Display data
Counter Content
Max. number
of histories
Remarks
Display Content
JAM CODE/
TROUBLE
CODE
DATE/TIME
TOTAL
COUNT(BW)
TOTAL
COUNT(CL)
PAPER JAM PAPER
JAM
COUNT
Number of
machine
JAM
troubles
Generated
JAM code
(Machine)
Generated
date/time
(YY/MM/DD
HH:MM:SS)
Total output
quantity of
black and
white
Total output
quantity of
color
50
The head is the latest, and the
bottom is the oldest. The max.
number of histories is 50.
SPF JAM SPF JAM
COUNT
Number of
SPF JAM
troubles
Generated
JAM code
(SPF)
50
When 50 is exceeded, the oldest
one is not displayed sequentially.
TROUBLE TROUBLE
COUNT
Number of
troubles
Generated
trouble code
30
The head is the latest, and the
bottom is the oldest. The max.
number of histories is 30.
When 30 is exceeded, the oldest
one is not displayed sequentially.
Item Content
PAPER JAM COUNT Number of machine JAM troubles
PAPER FEED COUNTER Paper feed counter (Similar with
SIM22-09 display content)
PAPER FEED RETRY COUNTER Paper feed retry counter (Similar
with SIM27-18 display content)
Item Content Description
NO No History number
JAM CODE JAM Code Jam code main
DATE/TIME Date/Time Occurrence date
TOTAL_BW Total Count (BW) Total counter (B/W)
TOTAL_CL Total Count (CL) Total counter (color)
P_S (*1) Paper Size Paper size
P_T (*1) Paper Type Paper type
JOB (*1) Job Mode Job mode
JN Job No First after JOB start or not
OF Offset Paper exit: Offset
EP Exit Position Paper exit: Exit position
PC Punch Paper exit: Punch
SP Staple Paper exit: Staple
Item Content
NO. History number
DATE/TIME Occurrence date
TH_M External air temperature sensor temperature/AD
value
HUD_M External air humidity sensor humidity/AD value
TH1_LSU LSU thermistor 1 temperature/AD value
TH2_LSU LSU thermistor 2 temperature/AD value
TH_UM Fusing upper main thermistor (differential)
temperature/AD value
TH_UM_CS Fusing upper main thermistor (compensation)
temperature/AD value
TUMD Fusing upper main thermistor (detection) AD value
TH_US1 Fusing upper sub thermistor (differential)
temperature/AD value
TH_US1_CS Fusing upper sub thermistor (compensation)
temperature/AD value
TU1D Fusing upper sub thermistor (detection) AD value
TH_LM1 Fusing lower main thermistor (differential)
temperature/AD value
TH_LM1_CS Fusing lower main thermistor (compensation)
temperature/AD value
TL1D Fusing lower main thermistor (detection) AD value
TH_US2 Fusing upper sub thermistor 2 temperature/AD value
TH_LM2 Fusing lower main thermistor 2 temperature/AD value
