MX-3114N CONSUMABLE PARTS 3 – 4

The numbers in the column of "Quantity in collective package" in the above list indicate the quantities for one package shipped from the factory.

Since, however, the products are treated as one piece or one set, their model names and necessary quantities must be specified when order-

ing. Pay attention to that.

B. 26 cpm/31 cpm machine

(1) Europe, Eastern Europe, Australia, New Zealand, Korea, Taiwan

When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.

Model name: Composed of the parts of 1 set

(2) Asia, Middle East

Item

Model

name

Content Life

Quantity in

collective package

Remarks

Fusing belt kit MX-361FB Fusing belt x 1 200K 10

Fuser belt guide collar x 2

Pressure roller kit MX-230LH Fusing roller x 1 200K 10

Pressure roller x 1

Web cleaning kit MX-360WB Web roller x 1 200K 10

Web guide shaft x 2

Web pressure roller x 1

Web pressure roller bearing x 2

Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 200K 10

Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 200K 10

PTC kit MX-230CU PTC unit x 1 200K 10

Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10

Filter kit MX-361FL Ozone filter x 1 300K 10

Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 10 5% coverage

for each color;

25% color ratio

Main charger kit MX-230MK Main charger unit

Cleaning gum AS AR

Cleaning blade AR

x 1

Drum

840K

Rotation

Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times

x 3

20 For MX-FN17

Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20

Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1

Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1

Fusing unit MX-361FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
