MX-3114N SIMULATION 6 – 114
66-9
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected sound message
to the line and the speaker. (Send level:
Soft SW setting)
* For details of sound messages, refer to
the sound message table of SIM66-08.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-09, the following
screen is displayed.
2) When a button of a sound message to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
3) When [EXECUTE] button is pressed, it is highlighted and a
sound message is sent.
4) To end signal send:
When [EXECUTE] button is pressed, it is highlighted and sig-
nal send is interrupted.
66-10
Purpose
Data clear
Function (Purpose)
Used to clear the FAX and image send
image data. (The confidential data are also
cleared.)
Section
FAX
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button.
3) After completion of clearing, press [CA] key to reboot the
machine.
66-11
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected signal at 300bps
to the line and the speaker. (Send level:
Max.)
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-11, the following
screen is displayed.
2) When a button of a sound message to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
3) When [EXECUTE] button is pressed, it is highlighted and a
sound message is sent.
4) To end signal send:
When [EXECUTE] button is pressed, it is highlighted and sig-
nal send is interrupted.
<300bps send signal table>
66-12
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected signal at 300bps
to the line and the speaker. (Send level:
Soft SW setting)
* For the kings of send signals at 300bps,
refer to SIM66-11, 300bps send signal
table.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-12, the following
screen is displayed.
2) When a button of a sound message to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
3) When [EXECUTE] button is pressed, it is highlighted and a
sound message is sent.
4) To end signal send:
When [EXECUTE] button is pressed, it is highlighted and sig-
nal send is interrupted.
66-13
Purpose
Setting
Function (Purpose)
Used to register dial numbers for SIM66-
14/15/16, Dial test. (Up to 20 digits can be
registered.)
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-13, the following
screen is displayed.
* The number saved in the memory is displayed in the column
of [PRESENT:]. (If there is no data, [-------] is displayed.)
2) Enter a number with 10-key.
The entered number is displayed in the column of [NEW:].
After entering 20 digits, 10-key is disabled (no response). Only
[C] key is enabled. (10-key [0] to [9], [*], [#], [C] key (back by
one digit))
3) When [SET] key is pressed after completion of entry, the
entered number is displayed (registered) in the column of
[PRESENT:]. The column of [NEW:] becomes blank.
66-14
Purpose
Adjustment
Function (Purpose)
Used to execute the dial pulse (10PPS)
send test and to adjust the make time.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-14, the following
screen is displayed.
2) When [EXECUTE] button is pressed, it is highlighted and the
dial pulse is sent from the line in the set make time.
3) To end the dial test, press [EXECUTE] button again. The but-
ton returns to the normal display and the test is terminated.
NO SIGNAL 11111 11110 00000
010101 00001
