Sharp MX-2314N Service Manual

MX-3114N OPERATIONAL DESCRIPTIONS 13 – 13
Signal name Name Function/Operation
ADUM ADU motor Drives the ADU and the transport roller in the right paper exit section.
FUM Fusing motor Drives the fusing section.
HPOS
(SHPOS)*
Shifter home positions sensor Detects the shifter home position.
OSM Offset motor Offsets (shifts) paper.
POD1 Paper exit detector 1 Detects paper transport from the fusing section.
POD2 Paper exit detector 2 Detects paper transport to the face-down paper exit tray.
POD3* Paper exit detector 3 Detects paper transport to the right paper exit tray.
POFM Paper exit cooling fan Cools the fusing section and the paper exit section.
POFM2 Paper exit cooling fan Cools the fusing section and the paper exit section.
POM Paper exit motor Drives the roller in the paper exit section.
PRTPD* Paper exit tray paper detector
(Right paper exit tray)
Detects paper empty in the paper exit tray (Right paper exit tray).
TFD2 Paper exit tray full detector
(Face-down tray)
Detects paper full in the face-down paper exit tray.
TFD3* Paper exit tray full detector
(Right paper exit tray)
Detects paper full in the right paper exit tray.
No. Name Function/Operation
1 Transport roller 6 (Drive) Transports paper transported from the fusing section to the paper exit section and the switchback section.
2 Transport roller 6 (Idle) Apply a pressure to paper and the transport roller to provide the transport power of the transport roller to
paper.
3 Paper exit roller 1 (Idle) Apply a pressure to paper and the paper exit roller to provide the transport power of the paper exit roller to
paper.
4 Paper exit roller 1 (Drive) Transports paper to the left paper exit section.
5 Paper exit roller 2 (Idle) Apply a pressure to paper and the paper exit roller to provide the transport power of the paper exit roller to
paper.
6 Paper exit roller 2 (Drive) Discharges paper to the right paper exit tray.
7 Paper exit gate Selects the paper path: to transport paper to the back surface print transport section or to the right tray.
8 Switchback gate Switchbacks paper to transport it to the back surface print section.

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
