Sharp MX-2314N Service Manual

MX-3114N OPERATIONAL DESCRIPTIONS 13 – 24
C. Process section equivalent circuit diagram
C. C. C. C.
Primary transfer output
C. C. C. C.
C. C.C. V.
MC-Grid output
(BK)
Secondary
transfer output
PTC output
MC-Grid
output
(C)
MC-Grid output
(M)
MC-Grid output
(Y)
Developing
output
(BK)
Developing output
(C, M, Y)
